– 6 –
BOX (UPPER) , ANTENNA
ANTENNA CORD SETTING
2
claw
2
claw
3
box (upper), antenna
1
three screws
Set the antenna cord as illustrated below,
then install the antenna box.
box (lower), antenna
coil leadantenna cord
antenna, ferrite-ro
d
