SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JACK KEY LCD
* 1-673-933-11 JACK BOARD
***********
< CAPACITOR >
C910 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C911 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C912 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< DIODE >
D902 8-719-974-51 DIODE SB20-03P
< FERRITE BEAD >
FB901 1-469-568-21 FERRITE 0uH
FB902 1-469-568-21 FERRITE 0uH
< JACK >
J901 1-778-153-21 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 6V)
< COIL >
L901 1-416-668-11 INDUCTOR 10uH
**************************************************************
* A-3663-312-A KEY BOARD, COMPLETE
********************
< CONNECTOR >
CN701 1-569-806-21 CONNECTOR, FPC 5P
< RESISTOR >
R701 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R702 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R703 1-216-835-11 METAL CHIP 15K 5% 1/16W
R704 1-216-839-11 METAL CHIP 33K 5% 1/16W
R705 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R706 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R707 1-216-835-11 METAL CHIP 15K 5% 1/16W
R708 1-216-839-11 METAL CHIP 33K 5% 1/16W
R709 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R710 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R711 1-216-835-11 METAL CHIP 15K 5% 1/16W
R712 1-216-839-11 METAL CHIP 33K 5% 1/16W
R713 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R714 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R715 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
< SWITCH >
S701 1-692-453-11 SWITCH, KEY BOARD
(TUNE/SCAN TIME SET +, >)
S702 1-692-453-11 SWITCH, KEY BOARD
(SNOOZE, SLEEP OFF/LIGHT)
S703 1-692-453-11 SWITCH, KEY BOARD (x OFF, ALARM RESET)
S704 1-692-453-11 SWITCH, KEY BOARD (RADIO SLEEP)
S705 1-692-453-11 SWITCH, KEY BOARD (CD u)
S706 1-692-453-11 SWITCH, KEY BOARD (1)
S707 1-692-453-11 SWITCH, KEY BOARD (2)
S708 1-692-453-11 SWITCH, KEY BOARD (3)
S709 1-692-453-11 SWITCH, KEY BOARD (4)
S710 1-692-453-11 SWITCH, KEY BOARD (5)
S711 1-692-453-11 SWITCH, KEY BOARD
(TUNE/SCAN TIME SET –, .)
S712 1-692-453-11 SWITCH, KEY BOARD
(ALARM TRACK/STATION)
S713 1-692-453-11 SWITCH, KEY BOARD (ALARM TIME)
S714 1-692-453-11 SWITCH, KEY BOARD (ALARM MODE)
S715 1-692-453-11 SWITCH, KEY BOARD (BAND)
**************************************************************
* A-3683-085-A LCD BOARD, COMPLETE (CD2000: US, CND)
* A-3683-087-A LCD BOARD, COMPLETE (CD2000: E, SP, JE)
* A-3683-103-A LCD BOARD, COMPLETE (CD2000S)
********************
3-033-545-01 PLATE, LIGHT GUIDE
3-033-560-01 HOLDER, LCD
3-033-564-01 TERMINAL (LITHIUM +), BATTERY
3-033-565-01 TERMINAL (LITHIUM –), BATTERY
3-033-573-01 SHEET (LCD)
3-035-202-01 SHEET (LCD), INSULATING
< CAPACITOR >
C401 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-104-848-11 TANTALUM CHIP 100uF 20% 4V
C405 1-110-569-11 TANTALUM CHIP 47uF 20% 6.3V
C406 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C409 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian model
JE : Tourist model
SP : Singapore model
To Next Page
