Sony ICF-M410L - Disassembly

4
ICF-M410L
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
9 Screw (+PTPWH 2 × 8)
1 Screw (+B 3 × 6)
3 Five s crews
(+BTP 3
× 14)
q; Two s crews (+P 2 × 8)
qf Two s crews
(+P 2
× 8)
6 S crew (+PTPWH 2.6 × 8)
7 S ide panel (L)
qs S ide panel (R)
qd Arm (jog)
8 JACK board
qg KEY board
qj MAIN board
qh Knob
2 Antenna, telescopic
Cabinet rear
4 Claws
qa Claws
Remove the Claws
Remove the Claws
Knob (jog)
5 Plate, contact
Cabinet (front) sub assy
