– 4 –
Note: Follow the disassembly procedure in the numerical order given.
REAR CABINET
SECTION 2
DISASSEMBLY
2
six screws
(BTP 3
×
25)
1
battery case li
d
4
rear cabinet
5
antenna lead
5
BATT lead (red)
3
two claws
5
BATT lead (white)
