REAR COVER
4. Unhook left side hooks.
① Grip the rear cover by hand and use a ruler or jig to remove the hook of the rear
cover back chassis.
② Flex the rear cover outward to remove the hook. Support set with arm.
1
2
Total rear cover back chassis : 2 hooks
SECTION 1: KD-43X8*K
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SMART CORE APPENDIX
1-1. DISASSEMBLY AND REMOVAL CAUTION
