Sony KV-32FX65E - Page 75

113
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
D
R6808 1-260-340-11 CARBON 10K 5% 1/2W
R6809 1-260-340-11 CARBON 10K 5% 1/2W
R6811 1-216-461-00 METAL OXIDE 5.6K 5% 2W
R6812 1-215-895-11 METAL OXIDE 3.3K 5% 2W
R6813 1-215-920-11 METAL OXIDE 3.3K 5% 3W
R6814 1-215-880-00 METAL OXIDE 10 5% 2W
R6815 1-215-880-00 METAL OXIDE 10 5% 2W
R6816 1-216-361-00 METAL OXIDE 0.22 5% 2W
R6817 1-216-361-00 METAL OXIDE 0.22 5% 2W
R6818 1-249-405-11 CARBON 100 5% 1/4W
R6819 1-247-807-31 CARBON 100 5% 1/4W
R6820 1-535-143-51 LEAD, JUMPER (20.0MM)
R6821 1-535-143-51 LEAD, JUMPER (20.0MM)
R6831 1-260-124-11 CARBON 120K 5% 1/2W
R6832 1-216-434-11 METAL OXIDE 1.8K 5% 1W
R6833 1-202-972-61 FUSIBLE 1 5% 1/4W
R6834 1-535-143-21 LEAD, JUMPER (12.5MM)
R6835 1-260-288-11 CARBON 0.47 5% 1/2W
R6837 1-215-919-11 METAL OXIDE 2.2K 5% 3W
R6838 1-214-905-11 METAL 47K 1% 1/2W
R6839 1-215-919-11 METAL OXIDE 2.2K 5% 3W
R6840 1-247-843-11 CARBON 3.3K 5% 1/4W
R6842 1-260-123-11 CARBON 100K 5% 1/2W
R6843 1-249-429-11 CARBON 10K 5% 1/4W
R6844 1-249-441-11 CARBON 100K 5% 1/4W
R6845 1-249-433-11 CARBON 22K 5% 1/4W
R6851 1-260-123-11 CARBON 100K 5% 1/2W
R6852 1-260-123-11 CARBON 100K 5% 1/2W
R6853 1-260-123-11 CARBON 100K 5% 1/2W
R6854 1-249-417-11 CARBON 1K 5% 1/4W
R6880 1-215-436-00 METAL 4.3K 1% 1/4W
R6885 1-215-493-00 METAL 1M 1% 1/4W
R6886 1-215-477-00 METAL 220K 1% 1/4W
R6887 1-215-461-00 METAL 47K 1% 1/4W
R6888 1-249-441-11 CARBON 100K 5% 1/4W
R6891 1-535-143-61 LEAD, JUMPER (5.0MM)
R6892 1-535-143-61 LEAD, JUMPER (5.0MM)
R6895 1-249-443-11 CARBON 0.47 5% 1/4W
R6896 1-249-443-11 CARBON 0.47 5% 1/4W
R6898 1-215-493-00 METAL 1M 1% 1/4W
R6899 1-215-493-00 METAL 1M 1% 1/4W
< RELAY >
RY6601 £ 1-755-266-11 RELAY, AC POWER
RY6602 £ 1-755-167-11 RELAY, AC POWER
< TRANSFORMER >
T6600 £ 1-431-616-11 TRANSFORMER, CONVERTER
T6601 £ 1-433-516-11 TRANSFORMER, CONVERTER (PIT)
T6651 1-431-732-21 TRANSFORMER, CONVERTER (SRT)
T6801 1-433-489-31 TRANSFORMER, FERRITE (HDT)
T6802 1-433-489-31 TRANSFORMER, FERRITE (HDT)
T6804 £ 1-453-340-21 TRANSFORMER ASSY, FLYBACK (NX4522//U214)
T6852 1-433-487-11 TRANSFORMER, FERRITE (DFT)
< THERMISTOR >
TH6600 £ 1-809-827-11 THERMISTOR, POSITIVE
TH6700 1-800-193-00 THERMISTOR
< CAPACITOR >
C6652 1-107-678-11 ELECT 4.7UF 20.00% 450V
C6682 1-535-143-61 LEAD,JUMPER (5.0MM)
C6814 1-117-641-11 FILM 7500PF 3.00% 1.2KV
C6815 1-117-836-11 FILM 6800PF 3.00% 1.5KV
C6825 1-115-514-11 FILM 0.22UF 5.00% 250V
C6826 1-115-520-11 FILM 0.68UF 5.00% 250V
< DIODE >
D6652 8-719-923-78 DIODE MTZJ-T-77-12
< RESISTOR >
R6810 1-215-920-11 METAL OXIDE 3.3K 5% 3W
R6836 1-249-432-11 CARBON 18K 5% 1/4W
R6856 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R6857 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R6858 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R6859 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R6897 1-215-485-00 METAL 470K 1% 1/4W
< CAPACITOR >
C6652 1-107-679-91 ELECT 10UF 20.00% 450V
(KV-32FX65B/32FX65E/32FX65K)
1-107-678-11 ELECT 4.7UF 20.00% 450V
(KV-32FX65U)
C6682 1-107-679-91 ELECT 10UF 20.00% 450V
(KV-32FX65B/32FX65E/32FX65K)
1-535-143-61 LEAD,JUMPER (5.0MM) (KV-32FX65U)
D Board Variant Parts KV-28FX65
D Board Variant Parts KV-32FX65
