Sony KV-32FX65E - Electrical Parts List: D1 Board; D1 Board Component Lists

114
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
C6814 1-117-640-11 FILM 6800PF 3.00% 1.2KV
C6815 1-117-835-11 FILM 6200PF 3.00% 1.5KV
C6825 1-117-662-11 FILM 0.18UF 5.00% 250V
C6826 1-115-519-11 FILM 0.56UF 5.00% 250V
< DIODE >
D6652 8-719-923-79 DIODE MTZJ-T-77-12A
(KV-32FX65B/32FX65E/32FX65K)
8-719-923-78 DIODE MTZJ-T-77-12 (KV-32FX65U)
< RESISTOR >
R6810 1-215-484-00 METAL OXIDE 3.9K 5% 3W
R6836 1-249-431-11 CARBON 15K 5% 1/4W
R6856 1-216-485-00 METAL OXIDE 5.6K 5% 3W
R6857 1-216-485-00 METAL OXIDE 5.6K 5% 3W
R6858 1-216-485-00 METAL OXIDE 5.6K 5% 3W
R6859 1-216-485-00 METAL OXIDE 5.6K 5% 3W
R6897 1-215-489-00 METAL 680K 1% 1/4W
4-382-854-11 SCREW (M3X10), P, SW (+)
< CAPACITOR >
C6100 1-136-165-00 FILM 0.1UF 5.00% 50V
C6101 1-136-165-00 FILM 0.1UF 5.00% 50V
C6102 1-136-165-00 FILM 0.1UF 5.00% 50V
C6103 1-163-205-00 CERAMIC CHIP 0.001UF 5.00% 50V
C6104 1-163-205-00 CERAMIC CHIP 0.001UF 5.00% 50V
C6105 1-126-967-11 ELECT 47UF 20.00% 50V
C6106 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V
C6108 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6109 1-126-967-11 ELECT 47UF 20.00% 50V
C6110 1-126-967-11 ELECT 47UF 20.00% 50V
C6112 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C6113 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6114 1-126-964-11 ELECT 10UF 20.00% 50V
C6115 1-163-005-11 CERAMIC CHIP 470PF 10.00% 50V
C6116 1-163-275-11 CERAMIC CHIP 0.001UF 5.00% 50V
C6117 1-163-275-11 CERAMIC CHIP 0.001UF 5.00% 50V
C6119 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6120 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C6121 1-126-964-11 ELECT 10UF 20.00% 50V
C6122 1-126-967-11 ELECT 47UF 20.00% 50V
C6125 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C6126 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C6127 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6128 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C6129 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C6131 1-126-964-11 ELECT 10UF 20.00% 50V
C6132 1-163-259-91 CERAMIC CHIP 220PF 5.00% 50V
C6199 1-163-229-11 CERAMIC CHIP 12PF 5.00% 50V
C6207 1-126-967-11 ELECT 47UF 20.00% 50V
C6208 1-126-967-11 ELECT 47UF 20.00% 50V
C6210 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6250 1-104-664-11 ELECT 47UF 20.00% 16V
C6253 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6254 1-136-177-00 FILM 1UF 5.00% 50V
C6255 1-136-177-00 FILM 1UF 5.00% 50V
C6256 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C6257 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6258 1-163-127-00 CERAMIC CHIP 270PF 5.00% 50V
C6259 1-110-501-11 CERAMIC CHIP 0.33UF 10.00% 16V
C6260 1-104-664-11 ELECT 47UF 20.00% 16V
C6261 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6262 1-136-165-00 FILM 0.1UF 5.00% 50V
C6263 1-163-109-00 CERAMIC CHIP 47PF 5.00% 50V
C6264 1-126-964-11 ELECT 10UF 20.00% 50V
C6306 1-126-964-11 ELECT 10UF 20.00% 50V
C6307 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6350 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C6351 1-126-967-11 ELECT 47UF 20.00% 50V
C6353 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6354 1-136-159-00 FILM 0.033UF 5.00% 50V
C6355 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C6356 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C6357 1-136-165-00 FILM 0.1UF 5.00% 50V
C6358 1-104-329-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6359 1-104-329-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6360 1-107-714-11 ELECT 10UF 20.00% 50V
C6361 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C6362 1-164-182-11 CERAMIC CHIP 0.0033UF 10.00% 50V
C6363 1-104-665-11 ELECT 100UF 20.00% 25V
C6364 1-136-347-11 FILM 0.0047UF 5.00% 630V
C6365 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C6367 1-104-329-11 CERAMIC CHIP 0.1UF 10.00% 50V
C6368 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6370 1-136-347-11 FILM 0.0047UF 5.00% 630V
C6373 1-136-153-00 FILM 0.01UF 5.00% 50V
*A-1640-382-A D1 Board, Complete
(KV-28FX65)
*A-1640-322-A D1 Board, Complete
(KV-32FX65B/32FX65E/32FX65K)
*A-1640-385-A D1 Board, Complete
(KV-32FX65U)
D1 Board, Common Parts
D
D1
