Dimensions
35
Dimensions
Front
Side
Bottom
(Without the stand)
Top
Side
(When setting the stand using positions B and C for the
mounting screws)
Mass:
Approx. 2.0 kg (4 lb 6.5 oz)
Approx. 2.6 kg (5 lb 12 oz) (when AC adaptor is
installed)
Top
(With the arm mount bracket)
222.4 (8
7
/
8
)
166 (6
5
/
8
)
183.5 (7
1
/
4
)
17.5 (
23
/
32
)
161.8 (6
3
/
8
)
148.8 (5
7
/
8
)
130 (5
1
/
8
)
70 (2
7
/
8
)60 (2
3
/
8
)
161.5 (6
3
/
8
)
149.6 (6)
5.6 (
1
/
4
)
13 (
17
/
32
)
1/4-20UNC Maximum depth
6 mm (1/4 inch)
3/8-16UNC Maximum depth
6 mm (1/4 inch)
4-M3 Maximum depth
6 mm (1/4 inch)
173.6 (6
7
/
8
)
55.2
(2
1
/
4
)
16
(
21
/
32
)
33.2
(1
5
/
16
)
25
(1)
100 (4)
27
(1
1
/
8
)
Unit: mm (inches)
38 (1
1
/
2
)
1/4-20UNC Maximum depth 6 mm
(1/4 inch)
3/8-16UNC Maximum depth 6 mm
(1/4 inch)
16
(
21
/
32
)
55.2 (2
1
/
4
)
