MHC-RV8 4-240-082-11 (1)
Additional Information
37
GB
Specifications
Amplifier section
HCD–RV8
The following are measured at AC 220V 50/60 Hz
DIN power output (rated) 160 + 160 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
210 + 210 watts
(6 ohms at 1 kHz,
10% THD)
SS–WGV8
The following are measured at AC 220V 50/60 Hz
Continuous RMS power output (reference)
180 watts
(8 ohms at 100 Hz,
10% THD)
Inputs
GAME (VIDEO): 1 Vp-p, 75 ohms
(phono jack)
GAME (AUDIO): Voltage 250 mV,
(phono jacks) impedance 47 kilohms
MD/VIDEO (AUDIO) IN: voltage 450 mV/250 mV,
(phono jacks) impedance 47 kilohms
MIC: sensitivity 1 mV,
(phone jack) impedance 10 kilohms
Outputs
VIDEO OUT: max. output level 1 Vp-p,
(phono jacks) unbalanced, Sync.
negative load impedance
75 ohms
AUDIO OUT: Voltage 250 mV
(phono jacks) impedance 47 kilohms
PHONES: accepts headphones of
(stereo mini jack) 8 ohms or more
FRONT SPEAKER: accepts impedance of 6 to
16 ohms
SURROUND SPEAKER: accepts impedance of
24 ohms or more
SUBWOOFER: accept impedance of
8 ohms or more
VIDEO CD/CD player section
System Compact disc and digital
audio system
Laser Semiconductor laser
(λ=795nm)
Frequency response 2 Hz – 20 kHz (±0.5 dB)
Wave length 795 nm
Video color system format NTSC, PAL
Tape player section
Recording system 4-track 2-channel stereo
Frequency response 50 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassette
Wow and flutter ±0.15% W.Peak (IEC)
0.1% W.RMS (NAB)
±0.2% W.Peak (DIN)
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna FM lead antenna
Antenna terminals 75 ohm unbalanced
Intermediate frequency 10.7 MHz
continued
