Help Guide
Home Audio System
MHC-V42D
Enjoying sound from a guitar
You can listen to sound from a guitar (not supplied) by connecting the guitar to the MIC2/GUITAR jack on the
system. You can also play the guitar and sing along by connecting a microphone to the MIC1 jack on the
system. Additionally, you can change the guitar’s sound by selecting a guitar effect.
To turn off the guitar mode
Press GUITAR on the system repeatedly until the GUITAR indicator lights off.
Note
Howling may occur when using electro-acoustic guitar with [O ˎDRIVE] effect. Press MIC LEVEL - repeatedly to reduce
the guitar volume. Otherwise, change to the other guitar effect.
Before disconnecting the guitar from the system, press MIC LEVEL - repeatedly to reduce the guitar volume.
4-748-035-41(1) Copyright 2019 Sony Corporation
Press MIC LEVEL - repeatedly to reduce the guitar volume level.
1
Use an instrument cable (not supplied) to connect a guitar to the MIC2/GUITAR jack.
2
Press GUITAR on the system repeatedly to select the guitar effect that you want to apply.
[CLEAN]: Original guitar sound. Recommended for electric guitar or electro-acoustic guitar.
[O ˎDRIVE]: Distorted sound similar to an overdriven guitar amplifier. Recommended for electric guitar.
[BASS]: Original guitar sound. Recommended for bass guitar.
The GUITAR indicator lights up.
3
Start playing the guitar and adjust the guitar volume.
The guitar sound is output from the system.
4
