Sony MHC-V73D Service Manual

MHC-V73D
11
Sony CONFIDENTIAL
For Authorized Servicer
SECTION 2
DISASSEMBLY
Note: Disassemble the unit in the order as shown below.
2-1. DISASSEMBLY FLOW
2-3. TOP-M PANEL SECTION
(Page 13)
2-4. LOADING-M PANEL SECTION
(Page 14)
2-5. REAR PANEL ST-M SECTION
(Page 15)
2-2. SIDE PANEL M-L, M-R SECTION
(Page 12)
2-6. DAB ASSEMBLY_UART (AEP), CDM SECTION
(Page 16)
2-7. CDM90-DVBU204//M
(Page 17)
2-9. SMPS BOARD
(Page 19)
2-8. SERVICE OPTICAL
DEVICE (7G),
FLEXIBLE FLAT CABLE
(Page 18)
SET
2-10. MOTHERBOARD BOARD
(Page 20)
2-12. FRONT PANEL SECTION
(Page 22)
2-13. FRONT PANEL ST-M SECTION, FRONT PANEL SW SECTION
(Page 23)
2-14. REAR CABINET SECTION
(Page 24)
2-15. LOUDSPEAKER (30CM) (WOOFER) (SP7)
(Page 25)
2-11. CHASSIS SECTION, MID HORN REAR-M SECTION
(Page 21)

JIG
When disassembling the unit, use the following
jig for speaker removal.
Part No. Description
J-2501-238-A JIG FOR SPEAKER REMOVAL
SYSSET
2020/06/1902:21:42(GMT+09:00)

Sony MHC-V73D Specifications

General

Type	Freestanding Public Address (PA) system
Control type	Buttons
Light effects	Yes
Product color	Black
Audio formats supported	MP3
Speaker type	-
Number of woofer drivers	1
Number of tweeter drivers	4
Wi-Fi	No
Bluetooth range	- m
Connectivity technology	Wired & Wireless
Power source type	AC
Power consumption (standby)	0.5 W
Frequency range	- Hz
RMS rated power	- W
Woofer diameter	300 mm
Tweeter diameter	40 mm
Country of origin	European Union

Weight and Dimensions

Depth	370 mm
Width	428 mm
Height	921 mm
Weight	21200 g
Package depth	416 mm
Package width	504 mm
Package height	997 mm
Package weight	2500 g
