A.F.D. qg (21, 22, 23)
D.B.F.B. (button/indicator) 8
(28)
DISPLAY 5 (19, 39)
Display 6 (20)
ECHO wh (24)
INPUT MODE q; (27)
INPUT SELECTOR qa (17, 18,
19, 24, 27)
IR (receptor) ql (33, 39)
KARAOKE ON/OFF (button/
indicator) wj (24)
KEY CONTROL #/2 4 (26)
MASTER VOLUME 9 (16, 17,
25, 38, 40)
MEMORY/ENTER qj (18, 40)
MIC 1 (jack) wf (24)
MIC 2 (jack) wd (24)
MIC 1 Tone knobs
LOW, MID, HIGH 2 (24)
MIC 2 Tone knobs
LOW, MID, HIGH 3 (24)
MIC 1 VOL wg (24)
MIC 2 VOL ws (24)
MOVIE qf (22, 28, 38)
MUSIC qd (23, 28, 38)
Music Tone knobs
LOW, MID, HIGH 7 (25)
MUSIC VOLUME qs (24, 25)
SCORE (button/indicator) wa
(26)
TUNING –/+ qk (17, 18)
VOCAL SELECT (button/
indicator) w; (26)
2CH qh (21, 23, 28)
?/1 (power) 1 (13, 28, 40)
List of button locations and reference pages
How to use this page
Use this page to find the location of buttons that are
mentioned in the text.
Ill
us
t
ra
ti
on num
b
er
r
DISPLAY 5 (19, 39)
RR
Name of button/part Reference page
ALPHABETICAL ORDER
A - L
M - Z
NUMBERS AND SYMBOLS
