Power Supply Unit Status Indicators / Specifications
Power Supply Unit Status
Indicators
The power supply unit status indicators show the status of
the power supply unit during operation and when the unit
is powered on. Whenever a power error is detected, it is
reflected immediately by the indicator.
Note
When the unit is powered on, the status indicators may
light momentarily in red and a whining sound may be
heard. This is not a malfunction. Power all of the installed
power supply units on.
Specifications
The following specifications show the reference
performance for this unit and individual option boards/
units.
Design and specifications are subject to change without
notice.
MVS-6000 Multi Format Switcher
Processor
General
Power requirements
100 to 240 V ±10% AC, 50/60 Hz
Current consumption
100 V: 7 A, 240 V: 3 A
Peak inrush current
(1) Power ON, current probe method: 42
A (100 V), 45 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1: 36 A
(230 V)
Operating temperature
5ºC to 40ºC (41ºF to 104ºF)
Performance guaranteed temperature
10ºC to 35ºC (50ºF to 95ºF)
Storage temperature
−20ºC to +60ºC (−4ºF to +140ºF)
Operating humidity
10% to 90%
Dimensions (w/h/d, excluding projections)
482×176×520 mm (19×7×20
1
/
2
inches)
Mass Approx. 26 kg (57 lb 5.1 oz) (when
equipped with all installable option
boards and option power supply unit)
Remote control connectors
CTRL RJ-45, Complies with 100Base-TX
standard
DATA RJ-45, Complies with 100Base-TX
standard
REMOTE 1, 2, 3, 4
D-sub 9-pin, female
Comply with RS-422A standard
Data transfer rate: 38.4 Kbps
GPI D-sub 25-pin, female
TTL inputs: 8
Relay contact outputs: 4 (30 V AC/DC,
0.1 A)
Open collector outputs: 4
Meaning of status indicator displays
Indicator
color
Status Description Steps to take
Green Lit Operating normally −
Red Lit Power supply unit fan
fault
Exchange the
fan unit
− Not lit Power supply unit
fault
Exchange the
power unit
