The
Sony
MXP-210
is
a
multipurpose
audio
mixer
which
has
all
the
essential
functions
required
for
a
public
address
system,
radio
and
TV
broadcasting,
studio
recording
and
tape
editing.
Thanks
to
its
compact
and
lightweight
design,
the
unit
can
be
used
as
a
portable
mixer
for
relay
broadcasting
as
well
as
a
studio-use
mixer.
Each
input
signal
level
can
be
independently
adjusted
to
suit
the
signal
output
from
the
connected
equipment
and
to
provide
excellent
mixing
through
its
own
low-cut
filter
and
equalization
circuits.
With
the
PAN
POT
(panoramic
potentiometer)
function,
each
input
sound
can
be
placed
at
a
desired
spot
between
the
left
and
right
channels.
When
an
echo
machine
or
a
reverberation
unit
is
additionally
connected
to
the
auxiliary
input
connector,
desired
sound
effects
may
be
easily
obtained.
One
of
the
outputs
can
be
used
to
supply
signals
to
a
fold-
back
speaker
for
players
on
the
stage.
Each
line
and
auxiliary
output
signal
and
also
an
input
signal
connected
to
the
monitor
input
connector
can
be
monitored
either
with
headphones
or
speakers
for
accurate
mixing.
In
addition,
the
PFL
(pre-fader
listening)
function
permits
direct
monitoring
of
each
original
incoming
signal.
The
built-in
power
supply
circuits
supply
the
required
power
of
48
V
DC
to
the
connected
phantom-powered
microphones
(designed
for
external
power
supply).
scp
Re
‘
The
MXP-210
can
easily
be
installed
on
a
console
table
which
can
accept
the
unit
mountable
in
a
19-inch
standard
rack
by
using
an
MXBK-200
rack
mount
adaptor
(optional),
or
can
be
placed
on
a
control
console
table
with
an
MXBK-201
table
kit
(optional)
attached.
