13
Notes on unit disposal
Remove the built-in lithium-ion battery when
disposing of the unit, and return the battery to a
recycling location.
The procedure for removing the battery is
explained below.
Note
Never disassemble the unit except when disposing of
it.
1 Press the RESET button to turn off the
unit.
2 Remove the 2 rubber plugs on the rear
of the unit, then remove the 4 screws
using a screw driver.
3 Detach the claws with a sharpened
object, such as a flat headed driver,
then remove the rear cover.
4 Remove the screw and battery as
shown below.
5 Insulate the connector terminal by
wrapping with a tape.
Notes on the lithium-ion battery
• Keep the battery out of the reach of children.
• Do not hold the battery with metallic tweezers,
otherwise a short-circuit may occur.
1
4
3
2
WARNING
Battery may explode if mistreated.
Do not recharge, disassemble, or dispose of
in fire.
To Next Page
