3-5. LCD BLOCK SUB ASSY, MAIN BOARD
7 switch unit (H)
(CN5003)
6 flexible board
(CN100)
4 sheet (shield HDD)
3 sheet (HDD)
2 reinforcement (HPJ)
5 sheet (insulating HDD flexible)
8 two toothed lock screw
s
(M1.4)
1 toothed lock screw
(M1.4)
1 toothed lock screw
(M1.4)
qa
qf
MAIN board
qs flexible boar
d
(CN5001)
q; claw
q; claw
qd LCD block sub assy
9 Remove the two solders.
