Sony ODS-D380U Service Manual

4-14. CA Upper Assembly
4-14-1. CA Upper Assembly
Required item
• Grease FLOIL (FLOIL G-902)
Tip
The following parts cannot be reused. Prepare the new parts.
• Retaining ring: 4 pcs
• Tape AS 1/2: 1 pc
Preparation
1. Remove the top cover assembly. (Refer to“4-2. Top Cover Assembly”.)
2. Remove the bottom plate assembly. (Refer to “4-3. Bottom Plate Assembly”.)
3. Remove the MC top reinforcing plate. (Refer to “4-4. MC Top Reinforcing Plate”.)
4. Remove the RE rear assembly. (Refer to “4-7. RE Rear Assembly”.)
5. Remove the power supply block. (Refer to “4-8. Power Supply Block”.)
6. Remove the carry loader assembly. (Refer to “4-11. Carry Loader Assembly”.)
ODS-D280U/ODS-D280F
4-35
