Chapter 6 Menu Displays and Detailed Settings
03 BLACK/FLARE MASTER BLACK (–99 to 99) Adjusts the master black level.
R BLACK (–99 to 99) Adjusts the R black level.
B BLACK (–99 to 99) Adjusts the B black level.
MASTER FLARE (–99 to 99) Adjusts the flare level of the
master.
R FLARE (–99 to 99) Adjusts the R flare level.
G FLARE (–99 to 99) Adjusts the G flare level.
B FLARE (–99 to 99) Adjusts the B flare level.
FLARE OFF/ON Turns the flare correction circuit
on or off.
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the output signal of TEST
OUT connector.
04 GAMMA GAMMA OFF/ON Turns the gamma correction
function on or off.
STEP GAMMA 0.35 to 0.45 to 0.90 Sets the gamma correction curve
by steps.
MASTER GAMMA (–99 to 99) Sets the master gamma
correction curve.
R GAMMA (–99 to 99) Sets the R gamma correction
curve.
G GAMMA (–99 to 99) Sets the G gamma correction
curve.
B GAMMA (–99 to 99) Sets the B gamma correction
curve.
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the output signal of TEST
OUT connector.
GAMMA TABLE STD/HG Selects the gamma type.
STD: Standard gamma
HG: Hyper gamma
GAM TABLE(STD) 1 to 5 to 6 Selects the standard gamma type.
1: Corresponds to SD camcorder
2: x 4.5 gain
3: x 3.5 gain
4: Corresponds to SMPTE-240M
5: Corresponds to ITU-R709
6: x 5.0 gain
GAM TABLE(HG) 1 to 4 Selects the hyper gamma type.
1: 325% to 100%
2: 460% to 100%
3: 325% to 109%
4: 460% to 109%
No. Page Item Settings Description
