Sony PS-LX310BT Service Manual

SERVICE MANUAL
Sony CONFIDENTIAL
For Authorized Servicer
PS-LX310BT
SPECIFICATIONS
STEREO TURNTABLE SYSTEM
US Model
Canadian Model
AEP Model
UK Model
Ver. 1.0 2019.02
Motor and Platter
Drive system
Belt-drive
Motor
DC motor
Platter
296 mm dia. (aluminum die-cast)
Speeds
33 1/3 and 45 rpm, 2 speed
Wow and utter
0.1% (WRMS)
S/N ratio
More than 50 dB (DIN-B) with the
supplied cartridge
Tone Arm
T
ype
Dynamic balanced J shaped arm
Eective arm length
197 mm
USB Connectivity (US, CND)
Output port
USB2.0 Plug-in power Type-B
Powered by PC (DC5V 100 mA)
Cartridge
T
ype
MM
Stylus pressure
3 g
Output level
2.5 mV
General
Power supply
DC 12 V 0.8 A (AC adaptor)
Power consumption
1.8 W
Dimensions
430 mm x 108 mm x 367 mm
(17 in x 4 3/8 in x 14 1/2 in)
(width/height/depth)
Weight
Approx. 3.5 kg (7 Ib 11 1/2 oz)
AC adaptor
Input
AC 100-240 V 0.35 A 50/60 Hz
Output
DC 12 V 0.8 A (AC adaptor)
BLUETOOTH section
Communication system
BLUETOOTH Specication version 4.2
Output
BLUETOOTH Specication Power
Class 2
Line of sight approx. 10 m (33 feet)*
Maximum communication range
Frequency band
2.4 GHz band (2.402 GHz - 2.480 GHz)
Modulation method
FHSS
Compatible BLUETOOTH proles*
2
A2DP 1.3
Supported Codecs*
3
SBC*
4
, Qualcomm® aptX™ audio
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency
44.1 kHz)
*
1
The actual range will vary depending on factors
* The 45 rpm adaptor and dust cover hinges are
attached to a side surface of your turntable's
packaging material.
such as obstacles between devices, magnetic elds
around a microwave oven, static electricity, cordless
phone, reception sensitivity, antenna's performance,
operating system, software application, etc.
*
2
BLUETOOTH standard proles indicate the purpose
of BLUETOOTH communication between devices.
*
3
Codec: Audio signal compression and conversion
format
*
4
Subband Codec
Design and specications are subject to
change without notice.
1
Checking the Supplied Items
t1MBUUFSXJUIESJWFCFMU
t.BUGPSUIFQMBUUFS
t%VTUDPWFS
tSQNBEBQUPS
t%VTUDPWFSIJOHFT
t"$BEBQUPS
t0QFSBUJOH*OTUSVDUJPOT
Maximum output power (AEP, UK)
≤ 4 dBm
SYSSET
2019/02/2300:40:47(GMT+09:00)

Sony PS-LX310BT Specifications

General

Drive System	Belt Drive
Bluetooth	Yes
Speeds	33 1/3, 45 RPM
Phono Preamp	Built-in
USB Output	No
Platter	Aluminum die-cast
Tonearm	Static balance
Motor	DC motor
Phono Output	Yes
Line Output	Yes
Cartridge Type	MM (Moving Magnet)
Auto Start	Yes
Auto Stop	Yes
Bluetooth Version	4.2
Bluetooth Profiles	A2DP, AVRCP
Dimensions	430 mm x 108 mm x 367 mm
Weight	3.5 kg
Cartridge	AT3600L
Power Supply	DC 12 V
