Port Screen
Chapter 4 Web Menu
Sync
Coarse adjustment of the sync phase.
–64 to 0
to 127
Fine
Fine adjustment of the sync phase.
0
to 1024
When using preview control on the PWA-PRC1, set the
Sync and Fine values to 0 (factory default values).
Color Space
Sets the color space of the output signal.
•Clip Data
• ITU-R BT.709
• ITU-R BT.2020
OETF
Selects the output signal OETF.
•SDR
•Clip Data
•S-Log3
•HLG
• PQ (ST2084)
Others
VIDEO OUT BLANK
Turns on/off vertical interval blanking processing of the
video signal output.
• Through
: Does not perform blanking processing.
• Blank: Performs blanking processing.
Y ADD
Selects whether to forcibly turn off “Y add.”
•Auto
•Off
Audio
Audio Output Select
Selects the file track to output for each audio output
channel.
AES/EBU
Selects the audio signal track that is output from the x-1
(main port) or x-2 (sub-port) on the AES/EBU 1/2 to 7/8
connectors when the port is set to “HD Output Multi.”
Shuttle Muting
Sets whether to output the audio signal during shuttle
playback.
•Off
: Audio is output.
• On: No output
VAR Muting
Sets whether to output the audio signal during variable-
speed playback (not using PLAY).
•Off
: Audio is output.
• On: Do not output
Audio Output Phase
Adjusts the audio output phase.
• 0 to 128
to 255 samples
Note
