Sony RDH-GTK37iP User Manual

12
GB
Insert the two supplied R6 (size AA)
batteries, matching the polarities shown
below.
Notes
• Do not mix an old battery with a new one or
mix different types of batteries.
• If you do not use the remote control for a long
period of time, remove the batteries to avoid
damage from battery leakage and corrosion.
The system can be installed either
vertically or horizontally. Select the
installation style based on your
preferences.
Notes
• Install the system horizontally when
connecting iPod nano model to the Terminal
for Apple Device.
• Be sure to select the vertical sound effect
when the system is installed vertically
(page 22).
– Vertical installation
– Horizontal installation
Using the iPod/iPhone
You can connect the models as follows to
the Terminal for Apple Device.
• iPod touch 5th generation
• iPod nano 7th generation
•iPhone 5
To prevent the iPod/iPhone from falling,
always secure the iPod/iPhone with the
holding arm when connecting to the
Terminal for Apple Device. When
removing the iPod/iPhone, lift up the
holding arm until it clicks and snaps into
position, and then disconnect the iPod/
iPhone from the Terminal for Apple
Device.
1 Place the iPod/iPhone onto the
Terminal for Apple Device.
2 Press the PUSH button until the
holding arm is released.
The holding arm flips out to secure the
iPod/iPhone.
Inserting batteries
Installing the system
When connecting to the
Terminal for Apple Device

Sony RDH-GTK37iP Specifications

General

Impedance	6 Ω
RMS rated power	420 W
Audio output channels	2.0 channels
Bluetooth	Yes
Headphone connectivity	-
Supported radio bands	AM, FM
Audio input	1
Power consumption (standby)	0.5 W
Power consumption (typical)	85 W
Product color	Black
Woofer diameter	200 mm
Tweeter diameter	66 mm

Weight and Dimensions

Depth	38.5 mm
Width	76.9 mm
Height	32.3 mm
Weight	14000 g
Package depth	44.9 mm
Package width	83.9 mm
Package height	41.6 mm
Package weight	17000 g
