5-19
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-DVD91E/DVD101/DVD101E
C4712 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4713 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4714 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C4715 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4716 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4717 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4718 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4719 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4720 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4724 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4725 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4726 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4731 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4732 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4733 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4734 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4735 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4736 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4737 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4738 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4802 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
C4803 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4804 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4806 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4808 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4809 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C4810 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C4811 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4812 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C4813 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4814 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4815 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4816 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4817 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C4819 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4820 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C4821 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4822 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
C4852 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4856 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C4857 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C4858 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C4859 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C4860 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C4861 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C4862 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4863 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4864 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4865 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4878 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4879 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4880 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4881 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4882 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4883 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4885 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4886 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4887 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4888 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4889 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4890 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4901 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4905 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C4906 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN4001 1-580-056-21 PIN, CONNECTOR (SMD) 3P
CN4002 1-580-056-21 PIN, CONNECTOR (SMD) 3P
CN4201 1-766-644-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 8P
(DVD101/DVD101E)
CN4501 1-817-727-11 CONNECTOR, FFC/FPC (ZIF) 40P
CN4801 1-784-419-11 CONNECTOR, FFC/FPC (ZIF) 15P
CN4851 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN4852 1-766-350-21 CONNECTOR, FFC/FPC 20P
CN4901 1-774-603-41 CONNECTOR, BOARD TO BOARD 100P
CN4902 1-750-303-41 CONNECTOR, BOARD TO BOARD 20P
CN4907 1-766-340-21 CONNECTOR, FFC/FPC 10P
CN4908 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D4001 8-719-027-76 DIODE 1SS357-TPH3
D4002 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D4003 8-719-081-19 DIODE 1SS383 (T5RSONY1)
D4004 8-719-421-67 DIODE MA132WK
D4007 8-719-074-08 DIODE MA4ZD03001S0
D4008 8-719-085-52 DIODE SBS806M-TL-E
D4009 8-719-421-67 DIODE MA132WK
D4200 8-719-421-27 DIODE MA728 (DVD101/DVD101E)
D4202 8-719-421-27 DIODE MA728 (DVD101/DVD101E)
D4203 8-719-056-85 DIODE UDZ-TE-17-8.2B (DVD101/DVD101E)
D4204 8-719-421-27 DIODE MA728 (DVD101/DVD101E)
D4501 8-719-073-01 DIODE MA111-(K8).S0
D4701 8-719-978-33 DIODE DTZ-TT11-6.8B
D4702 8-719-978-33 DIODE DTZ-TT11-6.8B
D4801 8-719-421-27 DIODE MA728
D4802 8-719-421-27 DIODE MA728
D4906 8-719-056-85 DIODE UDZ-TE-17-8.2B
D4907 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D4908 8-719-978-33 DIODE DTZ-TT11-6.8B
D4909 8-719-988-61 DIODE 1SS355TE-17
< TERMINAL >
ET4003 1-694-974-21 CONTACT TERMINAL
< FUSE >
0 F4001 1-576-406-21 FUSE 1.4A/32V
0 F4002 1-576-406-21 FUSE 1.4A/32V
0 F4003 1-576-406-21 FUSE 1.4A/32V
0 F4004 1-576-406-21 FUSE 1.4A/32V
0 F4005 1-576-406-21 FUSE 1.4A/32V
0 F4901 1-576-646-11 FUSE 0.5A/50V
MD-104
The components identified by mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce portant le numéro spécifié.
