Sony EMCS Co.
2005G1600-1
©2005.07
Published by DI Technical Support Department
9-876-714-83
SERVICE MANUAL
Ver 1.2 2005. 07
DCR-DVD91E/DVD101/DVD101E
• Change of the board suffix numbers (MD-104, VC-353)
SUPPLEMENT-2
File this supplement-2 with the service manual.
(PV04-017)
LEVEL 3
According to the change of board suffix numbers, the schematic
diagrams, printed wiring boards and electrical parts list are changed
as follows:
Before change After change
MD-104 BOARD
1-861-875 (-11) 1-861-875 (-13)
1-861-875 (-14)
VC-353 BOARD
1-861-870 (-11) 1-861-870 (-13)
1-861-870 (-12)
DCR-DVD91E/DVD101/
DVD101E
RMT-835
DCR-DVD101
US Model
Canadian Model
Korea Model
Japanese Model
DCR-DVD91E/
DVD101E
AEP Model
UK Model
East European Model
DCR-DVD91E
North European Model
DCR-DVD101E
Hong Kong Model
Australian Model
Chinese Model
DCR-DVD101/
DVD101E
E Model
Tourist Model
• Method of identifying the different printed wiring boards is shown on page 2.
• The MD-104 board with suffix-12 is intentionally not used so that the board
is not shown in the SERVICE MANUAL.
Ver 1.3 2005. 09
To Next Page
