5-27
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-DVD91E/DVD101/DVD101E
C3708 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3709 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3710 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3711 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3712 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3713 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3714 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3715 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3716 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3717 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3718 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3801 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C3802 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3803 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3804 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3805 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3806 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3807 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3810 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3811 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3812 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3813 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3814 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3815 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN1001 1-779-334-11 CONNECTOR, FFC/FPC 20P
CN1002 1-766-340-21 CONNECTOR, FFC/FPC 10P
CN1004 1-793-299-21 CONNECTOR, FPC (ZIF) 33P
CN1006 1-794-410-11 CONNECTOR, FPC (ZIF) 27P
CN1007 1-774-598-41 CONNECTOR, BOARD TO BOARD 100P
CN1008 1-766-350-21 CONNECTOR, FFC/FPC 20P
CN1201 1-816-595-31 CONNECTOR, FPC (ZIF) 23P
CN1301 1-784-423-21 FFC/CONNECTOR, FPC (ZIF) 39P
CN2201 1-779-334-11 CONNECTOR, FFC/FPC 20P
< DIODE >
D1001 6-500-776-01 DIODE MAZW068H0LS0
D1002 6-500-240-01 DIODE DF5A6.8JE (TPLR3)
D1003 6-500-240-01 DIODE DF5A6.8JE (TPLR3)
D1004 6-500-240-01 DIODE DF5A6.8JE (TPLR3)
D1005 6-500-776-01 DIODE MAZW068H0LS0
D1008 8-719-421-27 DIODE MA728
D1201 8-719-073-01 DIODE MA111-(K8).S0
D1202 8-719-075-62 DIODE 1SS401 (TE85L)
D1301 8-719-082-63 DIODE 1SV329 (TPL3)
D3104 8-719-056-23 DIODE MA2S111-(K8).SO
D3301 8-719-421-27 DIODE MA728
D3304 8-719-421-27 DIODE MA728
< FERRITE BEAD >
FB1001 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1002 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1003 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1004 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1005 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1006 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1007 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1008 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1009 1-500-444-11 FERRITE, EMI (SMD) (1608)
FB1301 1-469-676-22 BEAD, FERRITE (CHIP) (1608)
FB1302 1-469-676-22 BEAD, FERRITE (CHIP) (1608)
FB1303 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB1304 1-500-284-21 INDUCTOR, FERRITE BEAD
FB1305 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB1402 1-414-813-11 FERRITE, EMI (SMD) (2012) (DVD101/DVD101E)
FB2001 1-469-676-22 BEAD, FERRITE (CHIP) (1608)
(DVD101/DVD101E)
FB2101 1-469-676-22 BEAD, FERRITE (CHIP) (1608)
FB2201 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB2301 1-469-676-22 BEAD, FERRITE (CHIP) (1608)
FB3001 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB3102 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB3201 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB3202 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB3501 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB3502 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB3503 1-414-554-21 FERRITE, EMI (SMD) (1608)
< IC >
IC1101 8-759-489-19 IC uPC6756GR-8JG-E2
IC1201 8-759-337-40 IC NJM2904V (TE2)
IC1202 8-759-681-42 IC NJM12902V (TE2)
IC1203 6-702-931-01 IC M50230FP-DF1T
IC1301 8-752-417-70 IC CXD2444AR-T4
IC1302 8-759-699-92 IC AD80013AJSTRL
IC1303 8-759-387-31 IC TC75S55F (TE85R)
IC1401 6-706-193-01 IC CXD9560ZGF-TEB (DVD101/DVD101E)
IC1402 8-759-667-94 IC S-817A15ANB-CUE-T2 (DVD101/DVD101E)
IC1403 8-759-668-17 IC MB81F161622C-15PB-ER
(DVD101/DVD101E)
IC2001 6-701-740-01 IC MB87L4261LGA-G-ER (DVD101/DVD101E)
IC2101 6-701-656-01 IC AN2225NBBTBA
IC2201 8-752-110-48 IC CXM3007R-T4
IC2202 8-759-581-11 IC NJM2125F (TE2)
IC2301 8-759-826-24 IC LA74208GL-TBM-E
IC2302 8-759-826-26 IC AK4550VL-L
IC2401 8-759-638-50 IC AN2901FHQEBV
IC3001 6-804-148-01 IC MB91194ALGA-G-170-ER
IC3004 6-700-770-01 IC BR9016ARFVM-WTR
IC3103 6-804-090-01 IC MB89097LGA-G-173-ER
IC3203 6-704-205-01 IC HD6417190BPZ110CHV
IC3302 6-702-156-01 IC AK6510CM-E2
IC3401 6-804-185-01 IC MBM29DL324BE90PBT-83-ERE1
IC3501 8-752-421-48 IC CXD3157GA-T6
IC3502 6-704-445-01 IC BU2360FV-E2
IC3601 6-702-804-01 IC K4S28163LD-BL75T
IC3602 6-702-804-01 IC K4S28163LD-BL75T
IC3603 not supplied IC MB82D01161-90LPBT-ERWJE1 (Note)
IC3701 8-752-421-49 IC CXD3158GA-T6
IC3801 6-704-446-01 IC MD56V62320E-8LAZ
IC3803 6-704-446-01 IC MD56V62320E-8LAZ
VC-353
Note :
A service for IC3603 is not available because an
adjustment is required before replacement.
IC3603
