Sony RMT-V259 - Circuit Boards Location

2-4
2-8. CIRCUIT BOARDS LOCATION
2-4 E
JK-180
(SE500/SE800/
SX800)
(FRONT IN)
DS-91
(MODE CONTROL)
POWER BLOCK
(SRV938EK)
(POWER SUPPLY)
KK-23
(SE800/SX800)
(DIAL TIMER)
MA-373
VIDEO, AUDIO, I/O,
SERVO/SYSTEM CONTROL,
TUNER, MODE CONTROL
(
)
