SA-GN1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FH553 1-533-399-31 FUSE HOLDER
< IC >
IC301 6-600-182-01 IC STK-404-140S
IC601 8-759-634-51 IC NJM4558D
IC602 8-759-634-51 IC NJM4558D
IC603 8-759-634-51 IC NJM4558D
< TRANSISTOR >
Q302 8-729-119-78 TRANSISTOR 2SC2785TP-E
Q401 8-729-119-78 TRANSISTOR 2SC2785TP-E
Q402 8-729-178-42 TRANSISTOR 2SC2784-EFP-TP
Q403 8-729-119-78 TRANSISTOR 2SC2785TP-E
Q404 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q601 8-729-202-67 TRANSISTOR 2SK246GR3-TPE2
Q801 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q802 8-729-201-53 TRANSISTOR 2SA1015TP-GR
< RESISTOR >
R300 1-249-417-11 CARBON 1K 5% 1/4W F
0 R301 1-217-637-00 FUSIBLE 1 5% 1/4W
R302 1-249-433-11 CARBON 22K 5% 1/4W
R303 1-249-438-11 CARBON 56K 5% 1/4W F
R304 1-249-420-11 CARBON 1.8K 5% 1/4W F
0 R306 1-212-881-11 FUSIBLE 100 5% 1/4W
R308 1-249-428-11 CARBON 8.2K 5% 1/4W F
0 R312 1-234-182-11 ENCAPSULATED COMPONENT 0.22
R318 1-249-428-11 CARBON 8.2K 5% 1/4W F
R330 1-249-419-11 CARBON 1.5K 5% 1/4W F
R333 1-249-425-11 CARBON 4.7K 5% 1/4W F
R334 1-249-438-11 CARBON 56K 5% 1/4W
R354 1-215-857-00 METAL OXIDE 10 5% 1W
0 R400 1-216-458-11 METAL OXIDE 1.8K 5% 2W
R401 1-249-430-11 CARBON 12K 5% 1/4W
R402 1-249-438-11 CARBON 56K 5% 1/4W
R403 1-249-441-11 CARBON 100K 5% 1/4W
R404 1-249-441-11 CARBON 100K 5% 1/4W
R405 1-249-433-11 CARBON 22K 5% 1/4W
R406 1-249-433-11 CARBON 22K 5% 1/4W
R600 1-247-855-11 CARBON 10K 5% 1/4W
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-247-895-00 CARBON 470K 5% 1/4W
R603 1-247-895-00 CARBON 470K 5% 1/4W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-249-429-11 CARBON 10K 5% 1/4W
R607 1-249-425-11 CARBON 4.7K 5% 1/4W F
R608 1-247-895-00 CARBON 470K 5% 1/4W
R609 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-247-895-00 CARBON 470K 5% 1/4W
R611 1-249-425-11 CARBON 4.7K 5% 1/4W F
R613 1-249-425-11 CARBON 4.7K 5% 1/4W F
R614 1-249-425-11 CARBON 4.7K 5% 1/4W F
R615 1-249-425-11 CARBON 4.7K 5% 1/4W F
R616 1-247-903-00 CARBON 1M 5% 1/4W
R617 1-247-895-00 CARBON 470K 5% 1/4W
R618 1-249-437-11 CARBON 47K 5% 1/4W
R619 1-247-855-11 CARBON 10K 5% 1/4W
R630 1-249-430-11 CARBON 12K 5% 1/4W
R631 1-247-843-11 CARBON 3.3K 5% 1/4W
R638 1-247-887-00 CARBON 220K 5% 1/4W
R801 1-249-441-11 CARBON 100K 5% 1/4W
R802 1-249-441-11 CARBON 100K 5% 1/4W
R803 1-249-421-11 CARBON 2.2K 5% 1/4W F
R804 1-249-421-11 CARBON 2.2K 5% 1/4W F
R805 1-249-441-11 CARBON 100K 5% 1/4W
R806 1-249-441-11 CARBON 100K 5% 1/4W
< RELAY >
RY400 1-515-920-11 RELAY
******************************************************
1-687-520-11 PANEL BOARD
***********
< CAPACITOR >
C611 1-126-961-11 ELECT 2.2uF 20% 50V
< CONNECTOR >
* CN201 1-564-524-11 PLUG, CONNECTOR 9P
< DIODE >
D201 8-719-046-03 DIODE SEL5421E-TP15 (POWER)
< RESISTOR >
R201 1-249-414-11 CARBON 560 5% 1/4W F
< VARIABLE RESISTOR >
RV201 1-225-483-21 RES, VAR, CARBON 20K (CUT OFF FREQ)
RV202 1-225-483-21 RES, VAR, CARBON 20K (LEVEL)
******************************************************
1-687-519-11 POWER SWITCH BOARD
******************
< CAPACITOR >
0 C701 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN701 1-568-226-11 PIN, CONNECTOR (3.96mm PITCH)2P
< SWITCH >
0 S701 1-572-267-51 SWITCH, PUSH (AC POWER)(1 KEY) (POWER)
******************************************************
1-687-522-11 POWER TRANS BOARD
*****************
< CAPACITOR >
0 C501 1-113-925-11 CERAMIC 0.01uF 20% 250V
POWER TRANSPOWER SWITCHMAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
PANEL
