11
SA-GN1
< CONNECTOR >
CN501 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P
* CN502 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< RESISTOR >
0 R501 1-219-153-11 FUSIBLE 10 5% 1/4W
0 R502 1-219-153-11 FUSIBLE 10 5% 1/4W
< SWITCH >
0 S501 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (E,SP)
******************************************************
MISCELLANEOUS
*************
0 1-569-008-21 ADAPTOR, CONVERSION (SP)
055 1-777-071-53 CORD, POWER (SP)
055 1-791-901-12 CORD, POWER (E)
0F501 1-533-469-11 FUSE, GLASS TUBE (DIA.5) (2.5A/250V)
0 F502 1-533-471-11 FUSE, GLASS TUBE (DIA.5) (4A/250V)
0 F503 1-533-471-11 FUSE, GLASS TUBE (DIA.5) (4A/250V)
SP1 1-825-270-11 SPEAKER (20cm)
0 T501 1-439-638-11 POWER TRANSFORMER
******************************************************
ACCESSORIES
***********
1-751-598-53 CORD, CONNECTION (PIN-PIN)
4-235-237-01 FOOT
4-244-864-11 INSTRUCTION MANUAL
(ENGLISH,FRENCH,SPANISH,
TRADITIONAL CHINESE)
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
POWER TRANS
