Sony SA-VE155 - Page 9

9
SA-VE155/WMS155/SS-MS155
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN301 1-564-505-11 PLUG, CONNECTOR 2P
CN601 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
D603 8-719-991-33 DIODE 1SS133T-77
D801 8-719-312-47 DIODE RBA-406B
D802 8-719-921-88 DIODE MTZJ-13B
D803 8-719-921-88 DIODE MTZJ-13B
< IC >
IC601 8-759-584-38 IC TDA7296
< TRANSISTOR >
Q601 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q602 8-729-016-42 TRANSISTOR KTC3199GR-TP (E)
Q603 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q604 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q605 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q606 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q801 8-729-036-89 TRANSISTOR KTC3198GR-AT
Q802 8-729-037-02 TRANSISTOR KTA1266Y-AT
< RESISTOR >
R301 1-249-417-11 CARBON 1K 5% 1/4W
R601 1-249-421-11 CARBON 2.2K 5% 1/4W
R602 1-249-433-11 CARBON 22K 5% 1/4W
R603 1-249-433-11 CARBON 22K 5% 1/4W
R604 1-247-807-31 CARBON 100 5% 1/4W
R605 1-247-727-11 CARBON 10 5% 1/2W
R606 1-249-433-11 CARBON 22K 5% 1/4W
R607 1-247-761-11 CARBON 5.6K 5% 1/2W
R608 1-249-433-11 CARBON 22K 5% 1/4W
R609 1-249-435-11 CARBON 33K 5% 1/4W
R610 1-249-429-11 CARBON 10K 5% 1/4W
R613 1-249-430-11 CARBON 12K 5% 1/4W
R614 1-249-426-11 CARBON 5.6K 5% 1/4W
R615 1-249-429-11 CARBON 10K 5% 1/4W (E)
R616 1-249-429-11 CARBON 10K 5% 1/4W
R618 1-249-429-11 CARBON 10K 5% 1/4W
R619 1-249-441-11 CARBON 100K 5% 1/4W
R620 1-247-887-00 CARBON 220K 5% 1/4W
R801 1-260-292-11 CARBON 1 5% 1/2W F
R802 1-260-292-11 CARBON 1 5% 1/2W F
R803 1-247-843-11 CARBON 3.3K 5% 1/4W
R804 1-247-843-11 CARBON 3.3K 5% 1/4W
< RELAY >
RLY601 1-755-170-11 RELAY (12V)
< THERMISTOR (POSITIVE) >
TH601 1-809-789-71 THERMISTOR, POSITIVE (E)
*************************************************************
POWER SWITCH BOARD
********************
< CAPACITOR >
0 C810 1-135-450-51 FILM 0.01uF 10% 275V
< SWITCH >
0 SW801 1-786-749-11 SWITCH, POWER (POWER)
*************************************************************
TRANSFORMER BOARD
********************
1-533-313-11 HOLDER, FUSE
< CAPACITOR >
0 C813 1-135-450-51 FILM 0.01uF 10% 275V
< CONNECTOR >
CN801 1-564-506-11 PLUG, CONNECTOR 3P
CN802 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN803 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
0 F801 1-532-389-51 FUSE (T0.5AL/250V)
< TRANSFORMER >
0 T801 1-443-372-11 TRANSFORMER, POWER
*************************************************************
MISCELLANEOUS
***************
0 3 1-696-570-11 CORD, POWER (UK)
0 3 1-769-744-52 CORD, POWER (AEP,E)
SP1 1-825-843-11 SPEAKER (16cm) (WOOFER)
*************************************************************
ACCESSORIES
************
0 1-569-008-32 ADAPTOR, CONVERSION (E)
2-021-397-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
SPANISH,PORTUGUESE)
2-021-397-21 MANUAL, INSTRUCTION (GERMAN,ITALIAN,
DUTCH,SWEDISH) (AEP)
2-021-397-31 MANUAL, INSTRUCTION (DANISH,FINNISH,
POLISH,RUSSIAN) (AEP)
2-021-397-41 MANUAL, INSTRUCTION
(SIMPLIFIED CHINESE,
TRADITIONAL CHINESE) (E)
POWER SWITCH TRANSFORMERPOWER
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
