SA-VE155/WMS155/SS-MS155
SECTION 4
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. µPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONTROL BOARD
***************
< CAPACITOR >
C501 1-107-473-11 CERAMIC 220PF 5% 50V
C502 1-126-964-11 ELECT 10uF 20% 50V
C503 1-107-473-11 CERAMIC 220PF 5% 50V
C504 1-101-004-00 CERAMIC 0.01uF 50V
C505 1-101-004-00 CERAMIC 0.01uF 50V
C506 1-126-964-11 ELECT 10uF 20% 50V
C507 1-131-695-11 FILM 0.18uF 5% 50V
C508 1-131-691-11 FILM 0.082uF 5% 50V
C509 1-131-695-11 FILM 0.18uF 5% 50V
C510 1-136-165-00 FILM 0.1uF 5% 50V
C511 1-126-964-11 ELECT 10uF 20% 50V
C512 1-126-964-11 ELECT 10uF 20% 50V
C513 1-101-004-00 CERAMIC 0.01uF 50V
C514 1-101-004-00 CERAMIC 0.01uF 50V
C516 1-136-165-00 FILM 0.1uF 5% 50V
C517 1-136-165-00 FILM 0.1uF 5% 50V
C518 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN501 1-564-507-11 PLUG, CONNECTOR 4P
< IC >
IC501 8-759-634-51 IC M5218AP
IC502 8-759-634-51 IC M5218AP
< JACK >
J501 1-774-785-11 JACK, PIN 1P (LINE IN)
< RESISTOR >
R501 1-249-433-11 CARBON 22K 5% 1/4W
R502 1-249-441-11 CARBON 100K 5% 1/4W
R503 1-249-437-11 CARBON 47K 5% 1/4W
R504 1-249-439-11 CARBON 68K 5% 1/4W
R505 1-249-441-11 CARBON 100K 5% 1/4W
R506 1-249-427-11 CARBON 6.8K 5% 1/4W
R507 1-249-427-11 CARBON 6.8K 5% 1/4W
R508 1-249-434-11 CARBON 27K 5% 1/4W
R509 1-249-438-11 CARBON 56K 5% 1/4W
R511 1-249-434-11 CARBON 27K 5% 1/4W
R512 1-249-438-11 CARBON 56K 5% 1/4W
< VARIABLE RESISTOR >
VR501 1-227-666-11 RES, VAR 5K (LEVEL)
*************************************************************
LED BOARD
**********
< DIODE >
D301 8-719-080-25 LED SEL6414LF62 (POWER)
*************************************************************
A-1067-893-A POWER BOARD, COMPLETE (E)
A-4752-980-A POWER BOARD, COMPLETE (AEP,UK)
***********************
< CONNECTOR >
BC801 1-564-506-11 PLUG, CONNECTOR 3P
< CAPACITOR >
C601 1-126-960-11 ELECT 1uF 20% 50V
C602 1-131-695-11 FILM 0.18uF 5% 50V
C603 1-104-658-11 ELECT 100uF 20% 10V
C604 1-126-964-11 ELECT 10uF 20% 50V
C605 1-126-964-11 ELECT 10uF 20% 50V
C606 1-126-965-11 ELECT 22uF 20% 50V
C607 1-131-688-31 FILM 0.047uF 5% 50V
C608 1-102-973-00 CERAMIC 100PF 5% 50V
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-126-964-11 ELECT 10uF 20% 50V
C612 1-126-924-11 ELECT 330uF 20% 10V
C613 1-126-965-11 ELECT 22uF 20% 50V
C614 1-101-004-00 CERAMIC 0.01uF 50V
C801 1-126-955-11 ELECT 4700uF 20% 35V
C802 1-126-955-11 ELECT 4700uF 20% 35V
C803 1-101-004-00 CERAMIC 0.01uF 50V
C804 1-101-004-00 CERAMIC 0.01uF 50V
C805 1-126-964-11 ELECT 10uF 20% 50V
C806 1-126-964-11 ELECT 10uF 20% 50V
C807 1-126-964-11 ELECT 10uF 20% 50V
C808 1-126-964-11 ELECT 10uF 20% 50V
C809 1-101-005-00 CERAMIC 0.022uF 50V
C814 1-131-688-31 FILM 0.047uF 5% 50V
C815 1-131-688-31 FILM 0.047uF 5% 50V
CONTROL
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
