Sony SA-WMSP50 User Manual

10
SA-WMS145/WMSP50
MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CN301 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN402 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
< DIODE >
D205 8-719-110-31 DIODE RD12ES-B2
D206 8-719-110-31 DIODE RD12ES-B2
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D304 8-719-991-33 DIODE 1SS133T-77
0 D401 8-719-302-38 DIODE RBV-602-01
D402 8-719-024-99 DIODE 11ES2-NTA2B
D403 8-719-024-99 DIODE 11ES2-NTA2B
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* G1 1-537-738-21 TERMINAL, EARTH
* G2 1-537-738-21 TERMINAL, EARTH
< IC >
IC202 8-759-636-74 IC M5218AP-22
IC203 8-759-636-74 IC M5218AP-22
IC301 6-600-091-01 IC STK404-130S
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-178-42 TRANSISTOR 2SC2784-F
Q503 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q504 8-729-029-86 TRANSISTOR DTC124ESA
Q505 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R205 1-249-441-11 CARBON 100K 5% 1/4W
R206 1-249-429-11 CARBON 10K 5% 1/4W
R207 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-249-429-11 CARBON 10K 5% 1/4W
R209 1-249-441-11 CARBON 100K 5% 1/4W
R210 1-247-895-00 CARBON 470K 5% 1/4W
R211 1-247-887-00 CARBON 220K 5% 1/4W
R212 1-249-433-11 CARBON 22K 5% 1/4W
R213 1-249-433-11 CARBON 22K 5% 1/4W
R214 1-247-887-00 CARBON 220K 5% 1/4W
R216 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-441-11 CARBON 100K 5% 1/4W
R301 1-249-425-11 CARBON 4.7K 5% 1/4W
R302 1-249-437-11 CARBON 47K 5% 1/4W
R303 1-249-413-11 CARBON 470 5% 1/4W
0 R304 1-215-886-11 METAL OXIDE 100 5% 2W F
R305 1-249-437-11 CARBON 47K 5% 1/4W
R306 1-249-425-11 CARBON 4.7K 5% 1/4W
R307 1-249-425-11 CARBON 4.7K 5% 1/4W
0 R308 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R309 1-249-406-11 CARBON 120 5% 1/4W
R310 1-249-393-11 CARBON 10 5% 1/4W
0 R311 1-215-868-00 METAL OXIDE 680 5% 1W F
R312 1-249-433-11 CARBON 22K 5% 1/4W
R313 1-249-433-11 CARBON 22K 5% 1/4W
0 R314 1-217-637-00 FUSIBLE 1 5% 1/4W F
R315 1-249-437-11 CARBON 47K 5% 1/4W
0 R401 1-215-892-11 METAL OXIDE 1K 5% 2W F
0 R402 1-215-892-11 METAL OXIDE 1K 5% 2W F
0 R403 1-219-153-11 FUSIBLE 10 5% 1/4W F
0 R404 1-219-153-11 FUSIBLE 10 5% 1/4W F
R500 1-249-421-11 CARBON 2.2K 5% 1/4W
R501 1-249-429-11 CARBON 10K 5% 1/4W
R502 1-249-437-11 CARBON 47K 5% 1/4W
R503 1-249-441-11 CARBON 100K 5% 1/4W
R504 1-249-441-11 CARBON 100K 5% 1/4W
R505 1-249-433-11 CARBON 22K 5% 1/4W
R506 1-249-433-11 CARBON 22K 5% 1/4W
R507 1-249-425-11 CARBON 4.7K 5% 1/4W
R508 1-249-417-11 CARBON 1K 5% 1/4W
0 R601 1-215-920-11 METAL OXIDE 3.3K 5% 3W F
< RELAY >
RY301 1-755-417-12 RELAY
*************************************************************
1-688-814-11 POWER TRANS BOARD
*******************
1-533-223-11 HOLDER, FUSE
< CAPACITOR >
0 C2 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN2 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
*************************************************************
1-688-811-11 SWITCH BOARD
*************
< CAPACITOR >
0 C902 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
CN3 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< SWITCH >
0 S901 1-786-541-11 POWER SWITCH (PUSH) (POWER)
*************************************************************
MISCELLANEOUS
***************
0 54 1-769-744-11 CORD, POWER
0 58 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
0 F901 1-532-463-51 FUSE (T1AL/250V)
SP1 1-825-004-13 SPEAKER (20cm) (WOOFER)
0 T1 1-439-624-11 TRANSFORMER, POWER
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
SWITCHPOWER TRANS
