Sony SA-X9000F User Manual

HT-X9000F/XF9000
16
2-10. SK1-WS-CHUKEI BOARD
:LUHVHWWLQJ
front side
front side
right side
top side
CN1501
screw boss
screw boss
SK1-WS-CHUKEI board
right side
OK NG
Gap. (Do not touch
the shield main.)
Gap.
No gap. (Touch
the shield main.)
1 MAIN board cable
connector (CN1501)
bottom cabinet block
boss
hole
boss
hole
Twist the MAIN board
cable two times.
screw boss groove
groove
groove
packing (CZ2)
groove
groove
shield
main
shield
main
–7RSYLHZ–
left side
3 Draw the MAIN board cable
out of three grooves.
5 screw
(BVTP3 u 8)
6
SK1
-WS-CHUKEI board
Note:
When installing the SK1-WS-CHUKEI
board, align the two bosses and two holes.
3 Draw the MAIN board cable
out of two grooves.
5 screw
(BVTP3 u 8)
2 packing (CZ2)
CN702
Pass the MAIN board cable
beside the screw boss.
4 MAIN board cable
connector (CN702)
