Specifications
LCD panel Panel type: a-Si TFT Active Matrix
Picture size:
SDM-HS75P: 17.0 inch
SDM-HS95P: 19.0 inch
Input signal format
RGB operating frequency*
Horizontal:
28–80 kHz (analog RGB)
28–64 kHz (digital RGB)
Ver tic al :
48–75 Hz (analog RGB)
60 Hz (digital RGB)
Resolution Horizontal: Max.1280 dots
Vertical: Max.1024 lines
Input signal levels
Analog RGB video signal:
0.7 Vp-p, 75 Ω, positive
SYNC signal:
TTL level, 2.2 kΩ,
positive or negative
(Separate horizontal and
vertical)
Digital RGB (DVI) signal: TMDS
(Single link)
Power requirements
100–240 V, 50–60 Hz, Max. 1.0 A
Power consumption
SDM-HS75P: Max. 45 W
SDM-HS95P: Max. 60 W
Operating temperature
5–35°C
Dimensions (width/height/depth)
Display (upright):
SDM-HS75P
Approx. 388 × 382.5 × 139.2
mm
(15
1
/4 × 15 × 5
1
/2 inches)
SDM-HS95P
Approx. 435 × 418 × 146 mm
(17
1
/8 × 16
1
/2 × 5
3
/4 inches)
Mass SDM-HS75P: Approx. 5 kg
(11 lb.
3
/8 oz.)
SDM-HS95P: Approx. 6 kg
(13 lb. 3
5
/8 oz.)
Plug & Play DDC2B
Included itemsSee “Setup.”
* Recommended horizontal and vertical timing
condition
• Horizontal sync width duty should be more
than 4.8% of total horizontal time or 0.8
µsec, whichever is larger.
• Horizontal blanking width should be more
than 2.5 µsec.
• Vertical blanking width should be more than
450 µsec.
Design and specifications are subject to change
without notice.
