LINE-2
(DEC/EXT)LINE-3
(DEC/EXT)*!
21-pin
Video
input:
pin
20
Audio
input:
pins
2
and
6
~2
LINE-2
L-®
R*?
VIDEO
IN,
phono
jack
(1)
Input
signal:
1
Vp-p,
75
ohms,
unbalanced,
sync
negative
AUDIO
IN,
phono
jack
(2)
Input
level:
327
mVrms
Input
impedance:
more
than
47
kilohms
AUDIO
(OUT/SORTIE)
R/D
L/G*3
Phono
jack
(2)
Rated
output
level:
327
mVrms
Load
impedance:
47
kilohms
Output
impedance:
less
than
10
kilohms
*'
not
available
on
SLV-SE620N
*.
SLV-SE820N
only
*
not
available
on
SLV-SE620N
and
SE420K
General
Power
requirements
220
-
240
V
AC,
50
Hz
Power
consumption
15
W
(SLV-SE420K)
17
W
(SLV-SE820N,
SE720N,
SX720N
and
SE620N)
3
W
(POWER
SAVE
is
set
to
ON,
minimum)
Operating
temperature
5°C
to
40°C
Storage
temperature
—20°C
to
60°C
Dimensions
including
projecting
parts
and
controls
(w/h/d)
Approx.
360
=
95
x
243
mm
(SLV-SE420K)
Approx.
430
x
96
x
242
mm
(SLV-SE720N,
SX720N
and
SE620N)
Approx.
430
x
96
x
251
mm
(SLV-SE820N)
Mass
Approx.
2.8
kg
(SLV-SE420K)
Approx.
3.1
kg
(SLV-SE820N,
SE720N,
SX720N
and
SE620N)
Supplied
accessories
Remote
commander
(1)
R6
(size
AA)
batteries
(2)
Aerial
cable
(1)
Design
and
specifications
are
subject
to
change
without
notice.
SAFETY-RELATED
COMPONENT
WARNING!!
COMPONENTS
IDENTIFIED
BY
MARK
4
OR
DOTTED
LINE
WITH
MARK
4.
ON
THE
SCHEMATIC
DIAGRAMS
AND
IN
THE
PARTS
LIST
ARE
CRITICAL
TO
SAFE
OPERATION.
REPLACE
THESE
COMPONENTS
WITH
SONY
PARTS
WHOSE
PART
NUMBERS
APPEAR
AS
SHOWN
IN
THIS
MANUAL
OR
IN
SUPPLEMENTS
PUBLISHED
BY
SONY.
SAFETY
CHECK-OUT
After
correcting
the
original
service
problem,
perform
the
following
safety
checks
before
releasing
the
set
to
the
customer.
Check
the
area
of
your
repair
for
unsoldered
or
poorly-soldered
connections.
Check
the
entire
board
surface
for
solder
splashes
and
bridges.
Check
the
interboard
wiring
to
ensure
that
no
wires
are
"pinched"
or
contact
high-wattage
resistors.
Look
for
unauthorized
replacement
parts,
particularly
transistors,
that
were
installed
during
a
previous
repair.
Point
them
out
to
the
customer
and
recommend
their
replacement.
4.
Look
for
parts
which,
through
functioning,
show
obvious
signs
of
deterioration.
Point
them
out
to
the
customer
and
recommend
their
replacement.
Check
the
B+
voltage
to
see
it
is
at
the
values
specified.
Flexible
Circuit
Board
Repairing
*
Keep
the
temperature
of
the
soldering
iron
around
270°C
during
repairing.
*
Do
not
touch
the
soldering
iron
on
the
same
conductor
of
the
circuit
board
(within
3
times).
¢
Be
careful
not
to
apply
force
on
the
conductor
when
soldering
or
unsoldering.
