13
SRS-D4100/D5100
SECTION 4
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
•SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
KR : Korean model
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
AMP
A-4547-114-A AMP BOARD, COMPLETE (D5100: US, CND)
A-4547-162-A AMP BOARD, COMPLETE (D4100: US)
A-4547-341-A AMP BOARD, COMPLETE (D4100: AEP)
A-4547-343-A AMP BOARD, COMPLETE (D5100: AEP, UK, KR)
*******************
1-533-313-11 FUSE HOLDER
3-264-694-01 SHEET, INSULATING (B)
4-217-354-11 BUSHING, INSULATING (D5100)
7-682-549-04 SCREW +B 3X10 (D4100)
7-682-549-04 SCREW +B 3X10 (D5100)
< CAPACITOR >
C51 1-124-463-00 ELECT 0.1uF 20% 50V
C52 1-124-463-00 ELECT 0.1uF 20% 50V
(US, CND)
C52 1-126-160-11 ELECT 1uF 20% 50V
(AEP, UK, KR)
C53 1-124-584-00 ELECT 100uF 20% 10V
C54 1-126-963-11 ELECT 4.7uF 20% 50V
(D5100)
C55 1-126-964-11 ELECT 10uF 20% 50V
(D5100)
C58 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C59 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C125 1-124-252-00 ELECT 0.33uF 20% 50V
C126 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C127 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C128 1-131-702-11 FILM 0.68uF 5% 50V
C151 1-126-951-11 ELECT 470uF 20% 35V
C152 1-126-951-11 ELECT 470uF 20% 35V
C153 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C154 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C157 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C158 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C159 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C160 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C161 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C162 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C163 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C164 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C165 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C166 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C169 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C181 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C225 1-124-252-00 ELECT 0.33uF 20% 50V
C226 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C227 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C228 1-131-702-11 FILM 0.68uF 5% 50V
C281 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C325 1-124-252-00 ELECT 0.33uF 20% 50V
C326 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C327 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C328 1-131-702-11 FILM 0.68uF 5% 50V
C351 1-126-951-11 ELECT 470uF 20% 35V
C352 1-126-951-11 ELECT 470uF 20% 35V
C353 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C354 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C356 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C357 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C358 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C359 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C360 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C361 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C362 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C363 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C364 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C365 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C366 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C369 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C381 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C425 1-124-252-00 ELECT 0.33uF 20% 50V
C426 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C427 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C428 1-131-702-11 FILM 0.68uF 5% 50V
C481 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(D5100)
C522 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
C523 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(D5100)
C524 1-164-388-91 CERAMIC CHIP 270PF 5% 50V
(D5100)
C525 1-124-252-00 ELECT 0.33uF 20% 50V
(D5100)
C526 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(D5100)
C528 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
Ver 1.1
