SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
AMP
C529 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
(D5100)
C530 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
C531 1-126-951-11 ELECT 470uF 20% 35V
(D5100)
C532 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
C533 1-126-951-11 ELECT 470uF 20% 35V
(D5100)
C534 1-131-702-11 FILM 0.68uF 5% 50V
(D5100)
C581 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(D5100)
C621 1-124-465-00 ELECT 0.47uF 20% 50V
C622 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C623 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C624 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C625 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C626 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C627 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C628 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C629 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C630 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C631 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C632 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C633 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C634 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C635 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C637 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C638 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C639 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C640 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C641 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C642 1-128-552-51 ELECT 47uF 20% 63V
C643 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C644 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C645 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C646 1-131-702-11 FILM 0.68uF 5% 50V
C647 1-131-702-11 FILM 0.68uF 5% 50V
C648 1-131-696-11 FILM 0.22uF 5% 50V
C649 1-131-696-11 FILM 0.22uF 5% 50V
C650 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C651 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C652 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C653 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C654 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C655 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C656 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C657 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C658 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C661 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C662 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C663 1-126-951-11 ELECT 470uF 20% 35V
C664 1-126-951-11 ELECT 470uF 20% 35V
C666 1-126-947-11 ELECT 47uF 20% 35V
C667 1-126-947-11 ELECT 47uF 20% 35V
C901 1-119-939-11 ELECT 6800uF 20% 35V
C902 1-119-939-11 ELECT 6800uF 20% 35V
C903 1-119-939-11 ELECT 6800uF 20% 35V
C904 1-119-939-11 ELECT 6800uF 20% 35V
C905 1-126-942-61 ELECT 1000uF 20% 25V
C906 1-113-920-11 CERAMIC 0.0022uF 20% 250V
(AEP, UK, KR)
C909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C910 1-126-947-11 ELECT 47uF 20% 35V
C961 1-130-491-00 MYLAR 0.047uF 5% 50V
C962 1-130-491-00 MYLAR 0.047uF 5% 50V
C963 1-130-491-00 MYLAR 0.047uF 5% 50V
C964 1-130-491-00 MYLAR 0.047uF 5% 50V
< CONNECTOR >
CN601 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
(AEP, UK, KR)
CN903 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN904 1-564-674-11 PIN, CONNECTOR (3.96mm PITCH) 8P
< DIODE >
D51 8-719-988-61 DIODE 1SS355TE-17
D52 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-902-17 DIODE U15G
D902 8-719-902-17 DIODE U15G
D903 8-719-902-17 DIODE U15G
D904 8-719-902-17 DIODE U15G
D905 8-719-902-17 DIODE U15G
D906 8-719-902-17 DIODE U15G
D907 8-719-902-17 DIODE U15G
D908 8-719-902-17 DIODE U15G
D909 8-719-200-02 DIODE 10E-2
D910 8-719-200-02 DIODE 10E-2
D911 8-719-200-02 DIODE 10E-2
D912 8-719-200-02 DIODE 10E-2
< FERRITE BEAD >
FB101 1-400-160-51 INDUCTOR (SMALL TYPE)
FB102 1-400-160-51 INDUCTOR (SMALL TYPE)
FB601 1-400-160-51 INDUCTOR (SMALL TYPE)
FB602 1-400-160-51 INDUCTOR (SMALL TYPE)
FB603 1-400-160-51 INDUCTOR (SMALL TYPE)
FB604 1-400-160-51 INDUCTOR (SMALL TYPE)
< IC >
IC101 6-704-237-01 IC TDA7490L
IC301 6-704-237-01 IC TDA7490L
IC501 8-759-553-45 IC TDA7481 (D5100)
IC601 6-704-332-01 IC TDA8921TH
IC901 6-700-776-01 IC KIA78S09P-TP
< COIL >
L101 1-456-524-11 INDUCTOR 33uH
L301 1-456-524-11 INDUCTOR 33uH
L501 1-456-720-11 CIL, CHOKE 60uH (D5100)
L601 1-456-790-11 COIL, CHOKE 33uH
L602 1-456-790-11 COIL, CHOKE 33uH
Ver 1.1
