15
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< TRANSISTOR >
Q51 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q52 8-729-029-14 TRANSISTOR DTC144EUA-T106 (D5100)
Q53 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q54 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q55 8-729-028-91 TRANSISTOR DTA144EUA-T106
Q56 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q57 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q58 8-729-029-14 TRANSISTOR DTC144EUA-T106 (D5100)
Q59 8-729-029-14 TRANSISTOR DTC144EUA-T106 (D5100)
< RESISTOR >
R51 1-216-841-11 METAL CHIP 47K 5% 1/10W
R52 1-216-841-11 METAL CHIP 47K 5% 1/10W
R53 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R54 1-216-833-11 METAL CHIP 10K 5% 1/10W
R55 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R56 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R57 1-216-841-11 METAL CHIP 47K 5% 1/10W
R59 1-216-809-11 METAL CHIP 100 5% 1/10W
R60 1-216-841-11 METAL CHIP 47K 5% 1/10W
(D5100)
R61 1-216-841-11 METAL CHIP 47K 5% 1/10W
(D5100)
R62 1-216-834-11 METAL CHIP 12K 5% 1/10W
(D5100)
R63 1-216-833-11 METAL CHIP 10K 5% 1/10W
(D5100)
R64 1-216-809-11 METAL CHIP 100 5% 1/10W
R65 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R66 1-216-821-11 METAL CHIP 1K 5% 1/10W
R125 1-216-815-11 METAL CHIP 330 5% 1/10W
R126 1-216-815-11 METAL CHIP 330 5% 1/10W
R127 1-216-815-11 METAL CHIP 330 5% 1/10W
R151 1-218-331-11 METAL CHIP 51K 5% 1/10W
R152 1-218-882-11 METAL CHIP 30K 0.5% 1/10W
R153 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R154 1-216-833-11 METAL CHIP 10K 5% 1/10W
R155 1-216-843-11 METAL CHIP 68K 5% 1/10W
R156 1-216-837-11 METAL CHIP 22K 5% 1/10W
R157 1-218-743-11 METAL CHIP 130K 0.5% 1/10W
R158 1-216-837-11 METAL CHIP 22K 5% 1/10W
R159 1-216-843-11 METAL CHIP 68K 5% 1/10W
R160 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R161 1-218-331-11 METAL CHIP 51K 5% 1/10W
R162 1-216-795-11 METAL CHIP 6.8 5% 1/10W
R181 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R225 1-216-815-11 METAL CHIP 330 5% 1/10W
R226 1-216-815-11 METAL CHIP 330 5% 1/10W
R227 1-216-815-11 METAL CHIP 330 5% 1/10W
R281 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R325 1-216-815-11 METAL CHIP 330 5% 1/10W
R326 1-216-815-11 METAL CHIP 330 5% 1/10W
R327 1-216-815-11 METAL CHIP 330 5% 1/10W
R351 1-218-331-11 METAL CHIP 51K 5% 1/10W
R353 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R354 1-216-833-11 METAL CHIP 10K 5% 1/10W
R355 1-216-843-11 METAL CHIP 68K 5% 1/10W
R356 1-216-837-11 METAL CHIP 22K 5% 1/10W
R357 1-218-743-11 METAL CHIP 130K 0.5% 1/10W
R358 1-216-837-11 METAL CHIP 22K 5% 1/10W
R359 1-216-843-11 METAL CHIP 68K 5% 1/10W
R360 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R361 1-218-331-11 METAL CHIP 51K 5% 1/10W
R362 1-216-795-11 METAL CHIP 6.8 5% 1/10W
R381 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R425 1-216-815-11 METAL CHIP 330 5% 1/10W
R426 1-216-815-11 METAL CHIP 330 5% 1/10W
R427 1-216-815-11 METAL CHIP 330 5% 1/10W
R481 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R521 1-216-817-11 METAL CHIP 470 5% 1/10W
(D5100)
R522 1-216-834-11 METAL CHIP 12K 5% 1/10W
(D5100)
R523 1-216-817-11 METAL CHIP 470 5% 1/10W
(D5100)
R524 1-216-817-11 METAL CHIP 470 5% 1/10W
(D5100)
R581 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(D5100)
R621 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R622 1-218-882-11 METAL CHIP 30K 0.5% 1/10W
R623 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R624 1-216-799-11 METAL CHIP 15 5% 1/10W
R625 1-216-799-11 METAL CHIP 15 5% 1/10W
R626 1-215-859-00 METAL OXIDE 22 5% 1W
R627 1-215-859-00 METAL OXIDE 22 5% 1W
R629 1-216-809-11 METAL CHIP 100 5% 1/10W
R630 1-216-799-11 METAL CHIP 15 5% 1/10W
R631 1-216-799-11 METAL CHIP 15 5% 1/10W
R632 1-216-799-11 METAL CHIP 15 5% 1/10W
R633 1-216-799-11 METAL CHIP 15 5% 1/10W
************************************************************
A-4547-159-A CONTROL BOARD, COMPLETE (D4100)
A-4547-171-A CONTROL BOARD, COMPLETE (D5100)
**********************
< CAPACITOR >
C1 1-107-714-11 ELECT 10uF 20% 50V
C2 1-107-714-11 ELECT 10uF 20% 50V
C3 1-107-714-11 ELECT 10uF 20% 50V
C4 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5 1-126-933-11 ELECT 100uF 20% 16V
C6 1-124-259-11 ELECT 4.7uF 20% 50V
C7 1-124-259-11 ELECT 4.7uF 20% 50V
C8 1-124-259-11 ELECT 4.7uF 20% 50V
C9 1-124-259-11 ELECT 4.7uF 20% 50V
(D4100)
C10 1-124-259-11 ELECT 4.7uF 20% 50V
(D4100)
C101 1-124-259-11 ELECT 4.7uF 20% 50V
C102 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C103 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C104 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C105 1-124-259-11 ELECT 4.7uF 20% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
AMP
CONTROL
