16
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description RemarksRef. No. Part No. Description Remarks
CONTROL
C111 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C201 1-124-259-11 ELECT 4.7uF 20% 50V
C202 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C203 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C204 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C205 1-124-259-11 ELECT 4.7uF 20% 50V
C206 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C301 1-124-259-11 ELECT 4.7uF 20% 50V
C302 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C303 1-130-485-00 MYLAR 0.015uF 5% 50V
C304 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C305 1-124-259-11 ELECT 4.7uF 20% 50V
C306 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C311 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C401 1-124-259-11 ELECT 4.7uF 20% 50V
C402 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C403 1-130-485-00 MYLAR 0.015uF 5% 50V
C404 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C405 1-124-259-11 ELECT 4.7uF 20% 50V
C406 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C411 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C501 1-124-259-11 ELECT 4.7uF 20% 50V
(D5100)
C502 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(D5100)
C503 1-130-485-00 MYLAR 0.015uF 5% 50V
(D5100)
C504 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(D5100)
C505 1-124-259-11 ELECT 4.7uF 20% 50V
(D5100)
C511 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(D5100)
C601 1-124-259-11 ELECT 4.7uF 20% 50V
(D5100)
C602 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(D5100)
C603 1-124-259-11 ELECT 4.7uF 20% 50V
C604 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C605 1-124-259-11 ELECT 4.7uF 20% 50V
C606 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-124-259-11 ELECT 4.7uF 20% 50V
C704 1-124-259-11 ELECT 4.7uF 20% 50V
C705 1-124-259-11 ELECT 4.7uF 20% 50V
C706 1-126-933-11 ELECT 100uF 20% 16V
C707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C710 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C711 1-126-933-11 ELECT 100uF 20% 16V
C712 1-126-934-11 ELECT 220uF 20% 16V
C713 1-126-934-11 ELECT 220uF 20% 16V
C714 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C715 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C716 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C717 1-126-934-11 ELECT 220uF 20% 16V
C801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C802 1-126-933-11 ELECT 100uF 20% 16V
C803 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C804 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C805 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C806 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
* CN1 1-506-991-11 PIN, CONNECTOR (PC BOARD) 9P
< DIODE >
D701 8-719-077-29 DIODE SLC-22MG3F (POWER ON)
< IC >
IC1 8-759-100-96 IC uPC4558G2
IC701 8-759-385-17 IC NJM4580E (TE2)
IC801 8-759-100-96 IC uPC4558G2
IC802 8-759-100-96 IC uPC4558G2
IC803 8-759-100-96 IC uPC4558G2
< JACK >
J101 1-566-822-51 JACK (INPUT 1)
J102 1-566-822-51 JACK (INPUT 1)
J103 1-566-822-51 JACK (INPUT 1)
J104 1-566-822-51 JACK (INPUT 2) (D5100)
J701 1-815-325-11 JACK (PHONES)
< SHORT >
JR1 1-216-864-11 SHORT CHIP 0
JR2 1-216-864-11 SHORT CHIP 0 (D4100)
JR3 1-216-864-11 SHORT CHIP 0 (D4100)
JR4 1-216-864-11 SHORT CHIP 0 (D4100)
JR5 1-216-864-11 SHORT CHIP 0 (D4100)
JR6 1-216-864-11 SHORT CHIP 0 (D4100)
JR7 1-216-864-11 SHORT CHIP 0 (D4100)
JR8 1-216-864-11 SHORT CHIP 0 (D4100)
< TRANSISTOR >
Q703 8-729-038-58 TRANSISTOR KRA107S
Q704 8-729-038-71 TRANSISTOR KRC107S
Q705 8-729-920-31 TRANSISTOR DTC343TK
Q706 8-729-920-31 TRANSISTOR DTC343TK
< RESISTOR >
R1 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(D4100)
R1 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(D5100)
R2 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(D4100)
R2 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(D5100)
R5 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R9 1-216-837-11 METAL CHIP 22K 5% 1/10W
R10 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R11 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R12 1-216-809-11 METAL CHIP 100 5% 1/10W
(D5100)
