SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
JACK BOARD
*********
< CAPACITOR >
C57 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN101 1-566-006-11 PIN, CONNECTOR (PC BOARD) 9P
* CN102 1-506-784-11 PLUG, CONNECTOR (2.5mm) 10P
< JACK >
J105 1-817-577-11 JACK, DIN 8P (CONTROL)
J106 1-566-822-51 JACK (FRONT R)
J107 1-566-822-51 JACK (FRONT L)
J108 1-566-822-51 JACK (REAR R)
J109 1-566-822-51 JACK (REAR L)
J110 1-566-822-51 JACK (CENTER) (D5100)
************************************************************
MISCELLANEOUS
*************
2 1-825-753-11 SPEAKER UNIT (165mm)
0 6 1-696-169-12 CORD, POWER (AEP, UK)
0 6 1-769-079-32 CORD, POWER (KR)
0 6 1-783-531-72 CORD, POWER (US, CND)
58 1-828-481-11 DIN CABLE 9P (US, CND, KR)
58 1-828-481-21 DIN CABLE 9P (AEP, UK)
60 1-825-754-11 SPEAKER UNIT (57mm)
61 1-828-480-11 CORD CONNECTION 2P (US, CND)
61 1-828-480-21 CORD CONNECTION 2P (AEP, UK, KR)
0 F901 1-532-505-32 FUSE (T5AL/250V) (AEP, UK, KR)
0 F901 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A/125V)
(US, CND)
0 F902 1-532-505-32 FUSE (T5AL/250V) (AEP, UK, KR)
0 F902 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A/125V)
(US, CND)
0 F903 1-532-506-32 FUSE (T6.3AL/250V) (AEP, UK, KR)
0 F903 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5) (6.3A/125V)
(US, CND)
0 F904 1-532-506-32 FUSE (T6.3AL/250V) (AEP, UK, KR)
0 F904 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5) (6.3A/125V)
(US, CND)
0 F905 1-532-463-32 FUSE (T1AL/250V) (AEP, UK, KR)
0 F905 1-533-689-11 FUSE, GLASS CYLINDRICAL (DIA.5) (1A/125V)
(US, CND)
0 S901 1-762-876-11 SWITCH, AC POWER (AEP, UK, KR)
0 T901 1-443-207-11 TRANSFORMER, POWER (US, CND)
0 T901 1-443-209-11 TRANSFORMER, POWER (AEP, UK, KR)
******************************************************
ACCESSORIES
***********
A-4577-254-A BASE ASSY
1-828-477-11 CORD CONNECTION 6P (D5100: US, CND)
1-828-477-21 CORD CONNECTION 6P (D5100: AEP, UK, KR)
1-828-478-11 CORD CONNECTION 4P (D4100: US)
1-828-478-21 CORD CONNECTION 4P (D4100: AEP)
3-264-408-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH)
(D5100: US)
3-264-408-21 MANUAL, INSTRUCTION
(ENGLISH, SPANISH, FRENCH, GERMAN,
ITALIAN, DUTCH, PORTUGUESE, SWEDISH)
(D5100: AEP, CND, UK)
3-264-410-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH)
(D4100: US)
3-264-410-21 MANUAL, INSTRUCTION
(ENGLISH, SPANISH, FRENCH, GERMAN,
ITALIAN, DUTCH, PORTUGUESE, SWEDISH)
(D4100: AEP)
3-264-674-01 BOLT, SATELLITE
7-685-645-79 SCREW +P 3X6 TYPE2 NON-SLIT
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
JACK
Ver 1.1
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
