SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
4
Insert the jig (J-2501-238-A) into a space
and raise the front panel assy gradually.
Note: When using a jig, please work so as not to injure
front panel and speaker cabinet.
Insert the jig (J-2501-238-A) into a space
and raise the duct panel assy gradually.
Note: When using a jig, please work
so as not to injure duct panel assy
and speaker cabinet.
Insert the jig (J-2501-238-A) into a space
and raise the duct panel assy gradually.
Note: When using a jig, please work
so as not to injure duct panel assy
and speaker cabinet.
ten bosses
twelve bosses
front panel assy
duct panel assy
1-3. FRONT PANEL ASSY, DUCT PANEL ASSY (SS-MPS5000)
