Sony SS-SHAKE33 - Section 3 Electrical Parts List

8
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
SECTION 3
ELECTRICAL PARTS LIST
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “
*
” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
• Abbreviation
AR : Argentina model
AUS : Australian model
E2 : 120 V AC area in E model
E4 : African model
E12 : 220-240 V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
RU : Russian model
SAF : South African model
TH : Thai model
SPK LED SPLITTER
SPK LED BOARD
*************
< CONNECTOR >
CN1803 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
(SHAKE77/SHAKE88)
CN2700 1-580-057-11 PIN, CONNECTOR (SMD) 4P
(EXCEPT SHAKE77/SHAKE88)
(LED SPEAKER L/R)
< DIODE >
D1800 6-503-944-51 DI SMLVN6RGB1U17QYB (SHAKE77/SHAKE88)
D2700 6-503-944-51 DI SMLVN6RGB1U17QYB
(EXCEPT SHAKE77/SHAKE88)
< JUMPER RESISTOR >
JR2701 1-216-864-11 SHORT CHIP 0
(EXCEPT SHAKE77/SHAKE88)
JR2702 1-216-864-11 SHORT CHIP 0
(EXCEPT SHAKE77/SHAKE88)
JR2703 1-216-805-11 METAL CHIP 47 5% 1/10W
(EXCEPT SHAKE77/SHAKE88)
************************************************************
SPLITTER BOARD (SHAKE77/SHAKE88)
**************
< CONNECTOR >
CN1800 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
(LED SPEAKER L/R)
CN1801 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1802 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
Ref. No. Part No. Description Remark
The components identified by mark
0
or dotted line with mark
0
are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark
9
con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9
contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est rem-
placé et / ou réparé.
Ver. 1.2
