Sony SS-TS503 - Page 75

73
HCD-C770/C990
4.3 Vp-p
37 ns
eh IC206 <zc. (XIN)
4.2 Vp-
p
325 ns
3.9 Vp-
p
81 ns
4.4 Vp-
p
81 ns
ej IC606 qd (CKOUT)
ra IC606 wa (XOUT)
ek IC606 qf (BCK)
el IC606 qg (LRCK)
3.5 Vp-p
20.8 µ s
4.7 Vp-
p
325 ns
3.5 Vp-p
20.8 µ s
4.6 Vp-
p
81 ns
3.4 Vp-p
74.1 ns
rj IC607 qf (SCKOUT)
rk IC607 ql (LRCKO)
rl IC607 w; (BCKO)
rh IC607 qs (MCLK2)
r; IC606 w; (XMCK)
4.4 Vp-
p
81 ns
3.5 Vp-p
20.8 µ s
5 Vp-
p
325 ns
rs IC612 rd (F2BCK)
rd IC612 rf (F2LRCK)
rf IC612 rl (CKOUT)
5 Vp-
p
81 ns
rg IC612 ts (MCK)
4.2 Vp-
p
43 ns
1.8 Vp-
p
50 ns
t; IC901 ek (X2)
