75
HCD-C770/C990
1.4 Vp-p
H
1.4 Vp-
p
H
ys IC208 wa, ws (CbOUT) (NTSC Color Bars Play)
– VIDEO Board –
ya IC208 qk, ql (CrOUT)
(NTSC Color Bars Play)
2.1 Vp-
p
H
yd IC208 wf, wg (CYOUT), wj, wk (YOUT)
(NTSC Color Bars Play)
2.5 Vp-
p
H
yf IC208 e;, ea (VOUT) (NTSC Color Bars Play)
1.7 Vp-
p
H
yg IC208 ed(COUT) (NTSC Color Bars Play)
3.4 Vp-
p
231 ns
– AUDIO Board –
ua IC201 qf (X0)
2.2 Vp-p
504 ns
– FL Board –
oa IC802 tk (OSCO)
18.6 Vp-p
9.1 µs
– DDCON Board –
os Q803, 804 (Collector)
