Sony STR-AZ3000ES - Page 286

Help Guide
Multi Channel AV Receiver
STR-AZ7000ES/STR-AZ5000ES/STR-AZ3000ES
Using other HDMI or digital audio input jacks (Input Assign)
You can reassign video and/or audio signals to other input jacks if the default settings of the jacks do not correspond to your connected device.
E.g. When connecting a DVD player to the DIGITAL OPTICAL IN 1 (AUX) jack of the receiver, assign [BD/DVD] to the DIGITAL OPTICAL IN 1 (AUX) jack.
Assignable HDMI jacks (for STR-AZ7000ES/STR-AZ5000ES)
IN 1:
GAME (*1), MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX, TV, SA-CD/CD
IN 2:
GAME, MEDIA BOX (*1), BD/DVD, SAT/CATV, VIDEO, AUX, TV, SA-CD/CD
IN 3:
GAME, MEDIA BOX, BD/DVD (*1), SAT/CATV, VIDEO, AUX, TV, SA-CD/CD
IN 4:
GAME, MEDIA BOX, BD/DVD, SAT/CATV (*1), VIDEO, AUX, TV, SA-CD/CD
IN 5:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX (*1), TV, SA-CD/CD
IN 6:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX, TV, SA-CD/CD (*1)
IN 7:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO (*1), AUX, TV, SA-CD/CD
None (*2):
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX, TV (*1), SA-CD/CD
Assignable HDMI jacks (for STR-AZ3000ES)
IN 1:
GAME (*1), MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX, TV, SA-CD/CD
IN 2:
GAME, MEDIA BOX (*1), BD/DVD, SAT/CATV, VIDEO, AUX, TV, SA-CD/CD
IN 3:
GAME, MEDIA BOX, BD/DVD (*1), SAT/CATV, VIDEO, AUX, TV, SA-CD/CD
IN 4:
GAME, MEDIA BOX, BD/DVD, SAT/CATV (*1), VIDEO, AUX, TV, SA-CD/CD
IN 5:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO (*1), AUX, TV, SA-CD/CD
IN 6:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX, TV, SA-CD/CD (*1)
None: (*2)
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX (*1), TV (*1), SA-CD/CD
Assignable OPTICAL/COAXIAL input jacks
OPT1:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX (*), TV, SA-CD/CD
OPT2:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX, TV (*), SA-CD/CD
COAX:
GAME, MEDIA BOX, BD/DVD, SAT/CATV, VIDEO, AUX, TV, SA-CD/CD (*)
None:
GAME (*), MEDIA BOX (*), BD/DVD (*), SAT/CATV (*), VIDEO (*), AUX, TV, SA-CD/CD
Note
When you assign the digital audio input, the [Input Mode] setting may change automatically.
One reassignment is allowed for each input.
If no sound is output from the assigned jacks, also check the [Input Mode] settings.
5-037-021-11(1) Copyright 2022 Sony Corporation
Select [Setup] - [Input Settings] from the home menu.
1
Select [Assignment].
2
Select the input name you want to assign.
3
Press
(left)/ (right) repeatedly to select [HDMI] or [OPTICAL/COAXIAL].
4
Press
(up) / (down) repeatedly to select the jack you want to assign.
5
Default setting
*1
If the eARC/ARC function is activated, this item will be displayed as [OUT A(eARC/ARC)].
*2
Default setting
*1
If the eARC/ARC function is activated, this item will be displayed as [OUT A(eARC/ARC)].
*2
Default setting
*
197
