50
STR-DE685
Ref. No. Part No. Description Remark
S115 1-771-410-21 SWITCH, TACTILE (TUNER)
S116 1-771-410-21 SWITCH, TACTILE (VIDEO 3)
S117 1-771-410-21 SWITCH, TACTILE (SOUND FIELD MODE)
S118 1-771-410-21 SWITCH, TACTILE (PRESET/PTY SELECT +)
(AEP,UK,AUS)
S118 1-771-410-21 SWITCH, TACTILE (PRESET TUNING +)
(EXCEPT AEP,UK,AUS)
S120 1-771-410-21 SWITCH, TACTILE (FM/AM) (AEP,UK,AUS)
S120 1-771-410-21 SWITCH, TACTILE (FM) (EXCEPT AEP,UK,AUS)
S121 1-771-410-21 SWITCH, TACTILE (SHIFT)
S122 1-771-410-21 SWITCH, TACTILE (FM MODE)
S123 1-771-410-21 SWITCH, TACTILE (>)
S124 1-771-410-21 SWITCH, TACTILE (<)
S125 1-771-410-21 SWITCH, TACTILE (PTY) (AEP,UK,AUS)
S125 1-771-410-21 SWITCH, TACTILE (AM) (EXCEPT AEP,UK,AUS)
S126 1-771-410-21 SWITCH, TACTILE (MEMORY)
S127 1-771-410-21 SWITCH, TACTILE (TUNING +)
S130 1-771-410-21 SWITCH, TACTILE (AUX)
S131 1-771-410-21 SWITCH, TACTILE (DVD/LD)
S132 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO EX C)
S133 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO EX B)
S134 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO EX A)
S135 1-771-410-21 SWITCH, TACTILE (EQUALIZER)
S136 1-771-410-21 SWITCH, TACTILE (SOUND FIELD A.F.D.)
S137 1-771-410-21 SWITCH, TACTILE (SOUND FIELD 2CH)
*************************************************************
1-683-763-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-164-159-21 CERAMIC 0.1uF 50V
C792 1-113-342-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP791 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< JACK >
J791 1-815-313-21 JACK (PHONES) (JE,CH,SP,MY,KR)
J791 1-815-314-21 JACK (PHONES) (EXCEPT JE,CH,SP,MY,KR)
*************************************************************
1-683-764-11 JOG BOARD
**********
< CONNECTOR >
* CN101 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< ROTARY ENCODER >
RV101 1-418-817-11 ENCODER, ROTARY (JOG DIAL)
*************************************************************
A-4727-853-A MAIN BOARD, COMPLETE (US,CND)
A-4727-866-A MAIN BOARD, COMPLETE (AEP,UK,AUS)
A-4728-004-A MAIN BOARD, COMPLETE (TW)
A-4728-032-A MAIN BOARD, COMPLETE
(E,JE,MX,SP,MY,AR,KR)
A-4728-043-A MAIN BOARD, COMPLETE (CH)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-161-494-00 CERAMIC 0.022uF 25V
C372 1-161-494-00 CERAMIC 0.022uF 25V
C373 1-161-494-00 CERAMIC 0.022uF 25V
C374 1-164-159-21 CERAMIC 0.1uF 50V
C375 1-161-494-00 CERAMIC 0.022uF 25V
C376 1-161-494-00 CERAMIC 0.022uF 25V
C400 1-128-825-21 CERAMIC 0.0022uF 5% 50V
C401 1-126-964-11 ELECT 10uF 20% 50V
C402 1-126-964-11 ELECT 10uF 20% 50V
C404 1-126-964-11 ELECT 10uF 20% 50V
C405 1-126-964-11 ELECT 10uF 20% 50V
C406 1-126-964-11 ELECT 10uF 20% 50V
C407 1-126-964-11 ELECT 10uF 20% 50V
C408 1-126-964-11 ELECT 10uF 20% 50V
C409 1-126-964-11 ELECT 10uF 20% 50V
C411 1-126-961-11 ELECT 2.2uF 20% 50V
C412 1-126-961-11 ELECT 2.2uF 20% 50V
C413 1-126-964-11 ELECT 10uF 20% 50V
C414 1-126-964-11 ELECT 10uF 20% 50V
C415 1-126-964-11 ELECT 10uF 20% 50V
C416 1-126-964-11 ELECT 10uF 20% 50V
C417 1-126-964-11 ELECT 10uF 20% 50V
C418 1-126-964-11 ELECT 10uF 20% 50V
C419 1-126-964-11 ELECT 10uF 20% 50V
C431 1-126-961-11 ELECT 2.2uF 20% 50V
C432 1-126-961-11 ELECT 2.2uF 20% 50V
C433 1-126-964-11 ELECT 10uF 20% 50V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C454 1-126-964-11 ELECT 10uF 20% 50V
C455 1-126-964-11 ELECT 10uF 20% 50V
C456 1-126-964-11 ELECT 10uF 20% 50V
C457 1-126-964-11 ELECT 10uF 20% 50V
C458 1-126-964-11 ELECT 10uF 20% 50V
C459 1-126-964-11 ELECT 10uF 20% 50V
C461 1-126-961-11 ELECT 2.2uF 20% 50V
C462 1-126-961-11 ELECT 2.2uF 20% 50V
C464 1-164-159-21 CERAMIC 0.1uF 50V
C465 1-126-969-11 ELECT 220uF 20% 50V
C466 1-126-964-11 ELECT 10uF 20% 50V
C467 1-164-159-21 CERAMIC 0.1uF 50V
C471 1-126-963-11 ELECT 4.7uF 20% 50V
C472 1-126-963-11 ELECT 4.7uF 20% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C482 1-126-964-11 ELECT 10uF 20% 50V
C483 1-126-964-11 ELECT 10uF 20% 50V
C484 1-126-964-11 ELECT 10uF 20% 50V
C485 1-126-964-11 ELECT 10uF 20% 50V
Ref. No. Part No. Description Remark
MAINDISPLAY HEADPHONE JOG
Ver 1.1
