STR-DG500
2-662-258-12 (1)
Additional Information
Specifications
Amplifier section
Models of area code CEL, CEK, AU
Stereo Power Output
1)
, Reference Power
Output
1)2)
8 ohms 20 Hz – 20 kHz, THD 0.09%
85 W + 85 W, 110 W/ch
8 ohms 1 kHz, THD 0.7%
100 W + 100 W, 120 W/ch
8 ohms 1 kHz, THD 10%
125 W + 125 W, 150 W/ch
1)
Measured under the following conditions:
2)
Reference power output for front, center, surround
and surround back. Depending on the sound field
settings and the source, there may be no sound
output.
Frequency response
Analog 10 Hz – 70 kHz
+0.5/–2 dB (with sound
field and
equalizer
bypassed)
Inputs
Analog Sensitivity: 500 mV/
50 kohms
S/N
3)
: 96 dB
(A, 500 mV
4)
)
Digital (Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Digital (
Optical) S/N: 100 dB
(A, 20 kHz LPF)
Outputs (Analog)
AUDIO OUT Voltage: 500 mV/10 kohms
SUB WOOFER, SURROUND
Voltage: 2 V/1 kohm
Equalizer
Gain levels ±6 dB, 1 dB step
3)
INPUT SHORT (with sound field and equalizer
bypassed).
4)
Weighted network, input level.
FM tuner section
Tuning range 87.5 - 108.0 MHz
Intermediate frequency
10.7 MHz
Useable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono/Stereo 76 dB/70 dB
Harmonic distortion at 1 kHz
Mono/Stereo 0.3%/0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
AM tuner section
Tuning range
Intermediate frequency
450 kHz
Usable sensitivity 50 dB µ/m (at 1,000 kHz or
999 kHz)
Video section
Inputs/Outputs
Video: 1 Vp-p/75 ohms
S-video: Y: 1 Vp-p/75 ohms
C: 0.286 Vp-p/75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p/75 ohms
P
B/CB/B-Y: 0.7 Vp-p/
75 ohms
P
R/CR/R-Y: 0.7 Vp-p/
75 ohms
80 MHz HD Pass Through
Area code Power requirements
CEL, CEK 230 V AC, 50 Hz
AU 240 V AC, 50 Hz
Area code Tuning scale
10 kHz step 9 kHz step
CEL, CEK, AU – 531 –
1,602 kHz
continued
