Sony STR-DH590 Help Guide

Help Guide
MULTI CHANNEL AV RECEIVER
STR-DH590
No image appears on the TV screen.
Try pressing the input button on the remote control or turning INPUT SELECTOR on the receiver to select the input
to which you want to watch.
Set your TV to the appropriate input mode.
Make sure that cables are correctly and securely connected to devices.
Disconnect the HDMI cable from the receiver and TV, and then reconnect the cable.
Set “SIG. FMT.” of the selected input to “STANDARD” in the “<HDMI>” menu.
Some playback devices need to be set up. Refer to the operating instructions supplied with each device.
Be sure to use a High Speed HDMI Cable with Ethernet when you view images or listen to sound, especially for
1080p, Deep Color (Deep Colour), 4K or 3D transmission. Premium High Speed HDMI Cable with Ethernet, which
can support bandwidths up to 18 Gbps, is required for 4K/60p 4:4:4, 4:2:2 and 4K/60p 4:2:0 10 bit, etc.
If you want to play HDCP 2.2 content, connect the receiver to an HDMI input jack of a TV that is compatible with
HDCP 2.2.
4-731-210-11(1) Copyright 2018 Sony Corporation
102

Sony STR-DH590 Specifications

General

Receiver type	Surround
Output impedance	6 - 16 Ω
Audio output channels	5.2 channels
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	4
Digital audio optical in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	-
Bluetooth	Yes
Ethernet LAN	No
Supported radio bands	FM
Preset stations quantity	30
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS 96/24, DTS-HD HR, DTS-HD Master Audio, Dolby Digital, Dolby Dual Mono
Consumer Electronics Control (CEC)	BRAVIA Sync
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	297 mm
Width	430 mm
Height	133 mm
Weight	7100 g
