Sony STR-NX1 Service Manual

29
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101 1-674-803-11 TRANS BOARD
102 A-4426-238-A PA BOARD, COMPLETE (NX1: AEP, UK)
102 A-4426-246-A PA BOARD, COMPLETE (NX1: US, CND)
102 A-4426-255-A PA BOARD, COMPLETE (NX1: MY, SP, KR, JE)
102 A-4426-266-A PA BOARD, COMPLETE (NX3: AEP, UK)
102 A-4426-272-A PA BOARD, COMPLETE (NX3: US, CND)
102 A-4426-281-A PA BOARD, COMPLETE (NX3: E, AUS)
102 A-4426-938-A PA BOARD, COMPLETE (NX1: TH)
103 A-4426-260-A SURROUND AMP BOARD, COMPLETE (NX3)
0 104 1-575-651-11 CORD, POWER (NX3: MY, SP)
0 104 1-575-651-21 CORD, POWER (NX1: AEP, UK, MY, SP/NX3:
AEP, UK)
0 104 1-575-653-11 CORD, POWER (NX1: TH)
0 104 1-690-608-11 CORD, POWER (NX3: AUS)
0 104 1-690-609-21 CORD, POWER (CND)
0 104 1-769-079-21 CORD, POWER (KR)
0 104 1-775-789-21 CORD, POWER (JE)
0 104 1-783-531-31 CORD, POWER (US)
* 105 3-703-244-00 BUSHING (2104), CORD
(US, CND, AEP, UK, KR, MY, SP, AUS)
105 3-703-571-11 BUSHING (S) (4516), CORD (TH, JE)
106 A-4426-230-A MAIN BOARD, COMPLETE (NX1: AEP, UK)
106 A-4426-242-A MAIN BOARD, COMPLETE (NX1: US, CND)
106 A-4426-251-A MAIN BOARD, COMPLETE (NX1: MY, SP)
106 A-4426-261-A MAIN BOARD, COMPLETE (NX3: AEP, UK)
106 A-4426-269-A MAIN BOARD, COMPLETE (NX3: US, CND)
106 A-4426-277-A MAIN BOARD, COMPLETE (NX3: MY, SP)
106 A-4426-527-A MAIN BOARD, COMPLETE (NX3: KR, AUS)
106 A-4426-556-A MAIN BOARD, COMPLETE (NX1: JE)
106 A-4426-559-A MAIN BOARD, COMPLETE (NX1: KR)
106 A-4426-931-A MAIN BOARD, COMPLETE (NX1: TH)
0 107 1-569-007-11 ADAPTOR, CONVERSION 2P (JE)
0 107 1-569-008-21 ADAPTOR, CONVERSION 2P (MY, SP)
0 107 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
108 1-674-801-11 SUB TRANS BOARD (US, CND, AEP, UK)
109 4-221-364-01 CHASSIS
0 T951 1-433-993-11 TRANSFORMER, POWER (NX1: E, JE)
0 T951 1-433-994-11 TRANSFORMER, POWER (NX1: AEP, UK)
0 T951 1-433-995-11 TRANSFORMER, POWER (NX1: US, CND)
0 T951 1-433-996-11 TRANSFORMER, POWER (NX3: E, AUS)
0 T951 1-433-997-11 TRANSFORMER, POWER (NX3: AEP, UK)
0 T951 1-433-998-11 TRANSFORMER, POWER (NX3: US, CND)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
