Sony STR-NX1 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
31
C207 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C208 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C210 1-124-465-00 ELECT 0.47uF 20% 50V
(NX3)
C212 1-124-465-00 ELECT 0.47uF 20% 50V
(NX3)
C215 1-124-465-00 ELECT 0.47uF 20% 50V
(NX3)
C217 1-124-465-00 ELECT 0.47uF 20% 50V
(NX3)
C218 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C219 1-164-159-11 CERAMIC 0.1uF 50V
(NX3)
C221 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C224 1-162-282-31 CERAMIC 100PF 10% 50V
(NX3)
C225 1-162-306-11 CERAMIC 0.01uF 30% 16V
(NX3)
C226 1-126-160-11 ELECT 1uF 20% 50V
(NX3)
C227 1-164-159-11 CERAMIC 0.1uF 50V
(NX3)
C228 1-137-368-11 FILM 0.0047uF 5% 50V
(NX3)
C229 1-130-471-00 MYLAR 0.001uF 5% 50V
(NX3)
C231 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C233 1-136-169-00 FILM 0.22uF 5% 50V
(NX3)
C234 1-136-169-00 FILM 0.22uF 5% 50V
(NX3)
C235 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C237 1-137-368-11 FILM 0.0047uF 5% 50V
(NX3)
C238 1-130-471-00 MYLAR 0.001uF 5% 50V
(NX3)
C240 1-126-160-11 ELECT 1uF 20% 50V
(NX3)
C243 1-137-437-11 FILM 0.0056uF 5% 50V
(NX3)
C244 1-136-161-00 FILM 0.047uF 5% 50V
(NX3)
C245 1-136-175-00 FILM 0.68uF 5% 50V
(NX3)
C246 1-136-169-00 FILM 0.22uF 5% 50V
(NX3)
C247 1-136-169-00 FILM 0.22uF 5% 50V
(NX3)
C248 1-126-963-11 ELECT 4.7uF 20% 50V
(NX3)
C249 1-126-963-11 ELECT 4.7uF 20% 50V
(NX3)
C250 1-136-169-00 FILM 0.22uF 5% 50V
(NX3)
C251 1-136-169-00 FILM 0.22uF 5% 50V
(NX3)
C252 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C253 1-136-161-00 FILM 0.047uF 5% 50V
(NX3)
C254 1-136-161-00 FILM 0.047uF 5% 50V
(NX3)
C255 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C256 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C257 1-136-157-00 FILM 0.022uF 5% 50V
(NX3)
C258 1-136-157-00 FILM 0.022uF 5% 50V
(NX3)
C259 1-136-165-00 FILM 0.1uF 5% 50V
(NX3)
C260 1-136-357-11 FILM 680PF 5% 50V
(NX3)
C261 1-136-153-00 FILM 0.01uF 5% 50V
(NX3)
C262 1-136-357-11 FILM 680PF 5% 50V
(NX3)
C263 1-136-153-00 FILM 0.01uF 5% 50V
(NX3)
C264 1-136-153-00 FILM 0.01uF 5% 50V
(NX3)
C265 1-136-153-00 FILM 0.01uF 5% 50V
(NX3)
C266 1-104-664-11 ELECT 47uF 20% 16V
(NX3)
C267 1-130-481-00 MYLAR 0.0068uF 5% 50V
(NX3)
C268 1-126-963-11 ELECT 4.7uF 20% 50V
(NX3)
C269 1-126-934-11 ELECT 220uF 20% 16V
(NX3)
C270 1-126-934-11 ELECT 220uF 20% 16V
(NX3)
C274 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C275 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C276 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C277 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C278 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C279 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C280 1-126-964-11 ELECT 10uF 20% 50V
C281 1-162-286-31 CERAMIC 220PF 10% 50V
(NX3)
C282 1-162-286-31 CERAMIC 220PF 10% 50V
(NX3)
C283 1-162-286-31 CERAMIC 220PF 10% 50V
(NX3)
C284 1-124-465-00 ELECT 0.47uF 20% 50V
(NX3)
C285 1-124-465-00 ELECT 0.47uF 20% 50V
(NX3)
MAIN
