Sony STR-NX1 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
33
J102 1-785-009-11 JACK, PIN 6P (DVD 5.1CH INPUT: FRONT,
REAR, CENTER, WOOFER) (NX3)
J191 1-774-785-11 JACK, PIN 1P (SUPER WOOFER OUT)
< COIL >
L436 1-410-517-11 INDUCTOR 47uH
L501 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q112 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q113 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q114 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q162 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q163 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q164 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q191 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q281 8-729-141-30 TRANSISTOR 2SC3623ATP-LK (NX3)
Q282 8-729-141-30 TRANSISTOR 2SC3623ATP-LK (NX3)
Q291 8-729-141-30 TRANSISTOR 2SC3623ATP-LK (NX3)
Q411 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q421 8-729-900-63 TRANSISTOR BN1F4M-TP
Q431 8-729-111-29 TRANSISTOR 2SD1616-TP-LK
Q432 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q461 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q501 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q502 8-729-900-63 TRANSISTOR BN1F4M-TP
Q503 8-729-900-63 TRANSISTOR BN1F4M-TP
Q901 8-729-209-15 TRANSISTOR 2SD2012
Q902 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q903 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q904 8-729-900-36 TRANSISTOR BA1F4M-TP
Q905 8-729-900-36 TRANSISTOR BA1F4M-TP
Q906 8-729-040-20 TRANSISTOR RT1P137L-TP
Q907 8-729-900-36 TRANSISTOR BA1F4M-TP
Q921 8-729-026-68 TRANSISTOR 2SD2525 (TP)
Q923 8-729-040-20 TRANSISTOR RT1P137L-TP (NX3)
Q924 8-729-900-36 TRANSISTOR BA1F4M-TP (NX3)
Q951 8-729-141-83 TRANSISTOR 2SB1375
Q952 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q953 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W
R102 1-249-417-11 CARBON 1K 5% 1/4W
R103 1-249-417-11 CARBON 1K 5% 1/4W
R104 1-247-807-31 CARBON 100 5% 1/4W
R105 1-247-807-31 CARBON 100 5% 1/4W
R106 1-247-807-31 CARBON 100 5% 1/4W
R111 1-249-421-11 CARBON 2.2K 5% 1/4W
R112 1-249-429-11 CARBON 10K 5% 1/4W
R114 1-247-895-00 CARBON 470K 5% 1/4W
R115 1-247-899-11 CARBON 680K 5% 1/4W
R117 1-249-414-11 CARBON 560 5% 1/4W
R118 1-249-429-11 CARBON 10K 5% 1/4W
R119 1-249-438-11 CARBON 56K 5% 1/4W
R120 1-249-429-11 CARBON 10K 5% 1/4W
R121 1-249-437-11 CARBON 47K 5% 1/4W
R122 1-249-421-11 CARBON 2.2K 5% 1/4W
R123 1-249-441-11 CARBON 100K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R125 1-247-843-11 CARBON 3.3K 5% 1/4W
R126 1-249-421-11 CARBON 2.2K 5% 1/4W
R128 1-247-903-00 CARBON 1M 5% 1/4W
R131 1-247-807-31 CARBON 100 5% 1/4W
R132 1-247-807-31 CARBON 100 5% 1/4W
R133 1-247-807-31 CARBON 100 5% 1/4W
R141 1-249-433-11 CARBON 22K 5% 1/4W
R142 1-249-433-11 CARBON 22K 5% 1/4W
R143 1-249-417-11 CARBON 1K 5% 1/4W
R144 1-249-441-11 CARBON 100K 5% 1/4W
R145 1-247-903-00 CARBON 1M 5% 1/4W
R151 1-249-417-11 CARBON 1K 5% 1/4W
R152 1-249-417-11 CARBON 1K 5% 1/4W
R153 1-249-417-11 CARBON 1K 5% 1/4W
R154 1-247-807-31 CARBON 100 5% 1/4W
R155 1-247-807-31 CARBON 100 5% 1/4W
R156 1-247-807-31 CARBON 100 5% 1/4W
R161 1-249-421-11 CARBON 2.2K 5% 1/4W
R162 1-249-429-11 CARBON 10K 5% 1/4W
R164 1-247-895-00 CARBON 470K 5% 1/4W
R165 1-247-899-11 CARBON 680K 5% 1/4W
R167 1-249-414-11 CARBON 560 5% 1/4W
R168 1-249-429-11 CARBON 10K 5% 1/4W
R169 1-249-438-11 CARBON 56K 5% 1/4W
R170 1-249-429-11 CARBON 10K 5% 1/4W
R171 1-249-437-11 CARBON 47K 5% 1/4W
R172 1-249-421-11 CARBON 2.2K 5% 1/4W
R173 1-249-441-11 CARBON 100K 5% 1/4W
R174 1-249-429-11 CARBON 10K 5% 1/4W
R178 1-247-903-00 CARBON 1M 5% 1/4W
R191 1-249-417-11 CARBON 1K 5% 1/4W
R192 1-249-441-11 CARBON 100K 5% 1/4W
R193 1-249-417-11 CARBON 1K 5% 1/4W
R194 1-249-429-11 CARBON 10K 5% 1/4W
R201 1-249-441-11 CARBON 100K 5% 1/4W
(NX3)
R202 1-249-441-11 CARBON 100K 5% 1/4W
(NX3)
R222 1-249-417-11 CARBON 1K 5% 1/4W
(NX3)
R223 1-249-417-11 CARBON 1K 5% 1/4W
(NX3)
R224 1-249-417-11 CARBON 1K 5% 1/4W
(NX3)
R245 1-247-891-00 CARBON 330K 5% 1/4W
(NX3)
R260 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R261 1-247-876-11 CARBON 75K 5% 1/4W
(NX3)
R262 1-249-437-11 CARBON 47K 5% 1/4W
(NX3)
R263 1-247-876-11 CARBON 75K 5% 1/4W
(NX3)
R264 1-247-883-00 CARBON 150K 5% 1/4W
(NX3)
MAIN
