Sony STR-NX1 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
39
R633 1-249-411-11 CARBON 330 5% 1/4W
(NX3)
R636 1-249-411-11 CARBON 330 5% 1/4W
R637 1-249-411-11 CARBON 330 5% 1/4W
(US, CND, AEP, UK)
R638 1-249-411-11 CARBON 330 5% 1/4W
R641 1-249-403-11 CARBON 68 5% 1/4W
R642 1-249-403-11 CARBON 68 5% 1/4W
R643 1-249-403-11 CARBON 68 5% 1/4W
R651 1-249-401-11 CARBON 47 5% 1/4W
R652 1-249-429-11 CARBON 10K 5% 1/4W
R653 1-249-429-11 CARBON 10K 5% 1/4W
R654 1-249-429-11 CARBON 10K 5% 1/4W
R655 1-249-429-11 CARBON 10K 5% 1/4W
R656 1-249-417-11 CARBON 1K 5% 1/4W
R657 1-249-417-11 CARBON 1K 5% 1/4W
R661 1-247-807-31 CARBON 100 5% 1/4W
R662 1-247-807-31 CARBON 100 5% 1/4W
(NX3)
R663 1-247-807-31 CARBON 100 5% 1/4W
(NX3)
R666 1-247-807-31 CARBON 100 5% 1/4W
R667 1-247-807-31 CARBON 100 5% 1/4W
(US, CND, AEP, UK)
R668 1-247-807-31 CARBON 100 5% 1/4W
R669 1-247-807-31 CARBON 100 5% 1/4W
R703 1-249-429-11 CARBON 10K 5% 1/4W
R704 1-249-417-11 CARBON 1K 5% 1/4W
R705 1-249-441-11 CARBON 100K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W
R707 1-249-433-11 CARBON 22K 5% 1/4W
R708 1-249-429-11 CARBON 10K 5% 1/4W
R709 1-247-885-00 CARBON 180K 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV701 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH/ROTARY ENCODER >
S601 1-762-875-21 SWITCH, TACTILE (?/1)
S602 1-762-875-21 SWITCH, TACTILE (DISPLAY)
S603 1-762-875-21 SWITCH, TACTILE (POWER SAVE/DEMO
(STANDBY))
S604 1-762-875-21 SWITCH, TACTILE (VIDEO/DVD)
S605 1-762-875-21 SWITCH, TACTILE (MD)
S606 1-762-875-21 SWITCH, TACTILE (TAPE)
S607 1-762-875-21 SWITCH, TACTILE (CD)
S608 1-762-875-21 SWITCH, TACTILE (TUNER)
S609 1-762-875-21 SWITCH, TACTILE (DSP)
S610 1-762-875-21 SWITCH, TACTILE (DBFB)
S611 1-762-875-21 SWITCH, TACTILE (PLAY MODE)
S612 1-762-875-21 SWITCH, TACTILE (REPEAT)
S613 1-762-875-21 SWITCH, TACTILE (EDIT)
S614 1-762-875-21 SWITCH, TACTILE (FILE SELECT)
S615 1-762-875-21 SWITCH, TACTILE (TUNER BAND)
S616 1-762-875-21 SWITCH, TACTILE (STEREO/MONO)
S617 1-762-875-21 SWITCH, TACTILE (TUNER MEMORY)
S619 1-762-875-21 SWITCH, TACTILE (GROOVE)
S620 1-762-875-21 SWITCH, TACTILE (+ M)
S621 1-762-875-21 SWITCH, TACTILE (– m)
S622 1-762-875-21 SWITCH, TACTILE (ENTER)
S623 1-762-875-21 SWITCH, TACTILE (DVD 5.1CH) (NX3)
S624 1-762-875-21 SWITCH, TACTILE (PRO LOGIC) (NX3)
S651 1-473-392-11 ENCODER, ROTARY (VOLUME)
S652 1-473-534-11 ENCODER, ROTARY (JOG DIAL)
**************************************************************
* 1-675-197-11 R BOARD
*******
< CONNECTOR >
* CN607 1-565-835-11 SOCKET, CONNECTOR 3P
< IC >
IC601 8-749-011-05 IC GP1U28X (REMOTE CONTROL RECEIVER)
**************************************************************
1-674-801-11 SUB TRANS BOARD (US, CND, AEP, UK)
****************
< CAPACITOR >
C932 1-126-768-11 ELECT 2200uF 20% 16V
C933 1-164-159-11 CERAMIC 0.1uF 50V
C934 1-126-933-11 ELECT 100uF 20% 16V
0 C991 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN902 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D952 8-719-024-99 DIODE 11EQS04-NTA2B
D953 8-719-024-99 DIODE 11EQS04-NTA2B
D954 8-719-024-99 DIODE 11EQS04-NTA2B
D955 8-719-024-99 DIODE 11EQS04-NTA2B
D956 8-719-911-19 DIODE 1SS133T-72
D957 8-719-911-19 DIODE 1SS133T-72
< IC >
IC991 8-759-450-47 IC BA05T
< TRANSISTOR >
Q991 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R991 1-249-441-11 CARBON 100K 5% 1/4W
R992 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0 T901 1-433-999-11 TRANSFORMER, POWER (AEP, UK)
0 T901 1-435-059-11 TRANSFORMER, POWER (US, CND)
**************************************************************
PANEL R SUB TRANS
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
